FOXBORO P0914RD-OC Monitoring Module | Heat Balance Process Control
Manufacturer: Foxboro
-
Part Number: P0914RD-OC
Condition：New with Original Package
Product Type: Heat Balance Process Control
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The FOXBORO P0914RD-OC is a high-performance calorimetric monitoring module designed for Foxboro’s I/A Series Distributed Control System (DCS). It executes heat balance-based process control, enabling accurate thermal monitoring and energy flow analysis.
This module supports up to 16 analog inputs and 8 discrete inputs, collecting comprehensive process data. The redundant sensor algorithm ensures continuous, fault-tolerant operation, making the P0914RD-OC suitable for chemical processing, power generation, and refining applications where calorimetric control is critical.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | FOXBORO P0914RD-OC |
| Type | Calorimetric Monitoring Module |
| Analog Inputs | Up to 16 channels |
| Discrete Inputs | Up to 8 channels |
| Control Function | Heat balance-based process control |
| Redundancy | Redundant sensor algorithm for fault tolerance |
| Memory Configuration | 16 MB SDRAM, 32 MB Flash |
| Input Voltage | 24 V DC (supports redundant power input) |
| Power Consumption | ≤ 8.5 W (typical per non-redundant module) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Mounting Type | DIN rail or modular baseplate |
| Communication Protocols | HDLC Fieldbus, Modbus, Ethernet |
| Certifications | CE, UL, RoHS, IEC 61131-2 compliant |
FAQ
Q1: Is the FOXBORO P0914RD-OC brand new and original?
A1: Yes, the FOXBORO P0914RD-OC is fully new, original, and comes with a standard 12-month warranty.
Q2: How many input channels does this module support?
A2: It supports up to 16 analog inputs and 8 discrete inputs for versatile process monitoring.
Q3: What power supply does this module require?
A3: The module operates on 24 V DC and supports redundant power input for fault-tolerant operation.
Q4: Which industries commonly use this module?
A4: Industries such as chemical processing, power generation, and refining rely on this module for calorimetric control.
Q5: How long does shipping usually take?
A5: Stock is available, and shipping typically ranges from 3 days to 2 weeks depending on order size and logistics.
