Product Description – ABB PFEA113-65 Tension Electronics Module

Description / Product Summary

The ABB PFEA113-65 Tension Electronics Module is engineered for precise load-cell integration in continuous web handling environments. It provides stable and repeatable tension measurement, which helps operators maintain consistent product quality during high-speed production. Moreover, its IP65 housing ensures dependable operation in dusty or humid areas where standard electronics struggle to perform. The module processes signals from up to four load cells and delivers clear measurement feedback through its integrated display, allowing technicians to verify system status quickly. In addition, support for Profibus-DP communication enables seamless connection to modern automation platforms.

System Integration & Performance Overview

This module works as a central interface for tension control loops, combining analog and digital I/O with robust signal conditioning. The insulation amplifier on AO1 improves signal integrity, therefore allowing precise voltage output even in electrically noisy installations. Multiple analog outputs give system designers flexibility when routing tension signals to PLCs, drives, or local controllers. Furthermore, the PFEA113-65 simplifies commissioning because its display shows sum, difference, and individual load-cell readings, which supports efficient troubleshooting and calibration. Production teams appreciate the module’s reliability because it maintains accurate measurements despite temperature changes, vibration, or mechanical stress.

Technical Specifications

Model Number
PFEA113-65

Type
Tension Electronics Module

Housing Protection
IP65

Load Cell Inputs
4 inputs

Analog Outputs
6 AO selectable

Digital Outputs
4 DO

Digital Inputs
1 DI

Analog Inputs
2 AI

Display Functions
Sum, Difference, and individual cell values

Communication Protocols
Profibus-DP

Special Features
Insulation amplifier on AO1; high-accuracy signal handling

Gross Weight
4 kg

FAQ

Q1: What load-cell configurations does the ABB PFEA113-65 support?
A1: It supports up to four load-cell inputs and displays sum, difference, and individual readings for simplified setup.

Q2: Can this module integrate with fieldbus networks?
A2: Yes. It includes Profibus-DP communication for smooth integration with automation systems.

Q3: Is the PFEA113-65 suitable for harsh industrial environments?
A3: The IP65 housing protects the electronics from dust and moisture, therefore making it ideal for demanding applications.

Q4: How many analog outputs are available?
A4: The module provides six selectable analog outputs, including voltage and current options.

Q5: Which industries commonly use this tension controller?
A5: Typical installations include paper machines, printing presses, film production lines, and textile manufacturing systems.
