Bently Nevada 200200-06-06-05 Dual-Input Condition Monitoring Module
Manufacturer: Bently Nevada
-
Part Number: 200200-06-06-05
Condition：New with Original Package
Product Type: Dual-Input Condition Monitoring Module
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Bently Nevada 200200-06-06-05 – Dual-Input proTIM-R Module
Overview
The Bently Nevada 200200-06-06-05 is a dual-input proTIM-R module designed for seamless integration into the Trendmaster® Pro condition monitoring platform. It provides two independent channels that can be configured for either vibration or temperature measurement, enabling versatile deployment across industrial assets.
Each channel supports a wide range of sensors such as ICP® accelerometers, velocity transducers, K-type thermocouples, and Platinum RTDs. Its DIN rail mounting simplifies installation, while its rugged build ensures durability in harsh environments like refineries, power plants, and heavy manufacturing facilities.
Advanced signal conditioning—featuring Acceleration-to-Velocity (A-V) conversion and Acceleration Enveloping (AE)—allows engineers to capture both low-frequency and high-frequency fault data with high accuracy. This capability makes the module a key component for predictive maintenance programs.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | 200200-06-06-05 |
| Manufacturer | Bently Nevada (a Baker Hughes company) |
| Series | Trendmaster® Pro |
| Measurement Channels | 2 independent, configurable |
| Supported Inputs | A-V, AE, RTDs, Thermocouples |
| Sensor Compatibility | ICP® accelerometers, velocity sensors, K-type thermocouples, Platinum RTDs |
| Signal Conditioning | Acceleration-to-Velocity, Acceleration Enveloping |
| Frequency Response | 10 Hz to 1 kHz (typical for vibration inputs) |
| AE Input Frequency | Up to 10 kHz |
| Operating Temperature | –20°C to +65°C |
| Power Supply | 24 V DC |
| Mounting | DIN rail |
| Communication | RS-485 (Trendmaster® Pro network) |
| Electrical Isolation | Yes, for all input channels |
