Bently Nevada 330180-91-CN 3300 XL Proximitor Sensor
Manufacturer: Bently Nevada
-
Part Number: 330180-91-CN
Condition：New with Original Package
Product Type: 3300 XL Proximitor Sensor
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Bently Nevada 330180-91-CN – 3300 XL Proximitor Sensor
Overview
The Bently Nevada 330180-91-CN is part of the 3300 XL 8 mm Proximity Transducer System, designed to provide precise, non-contact vibration and position measurements in rotating equipment. This model features DIN rail mounting, which simplifies high-density installations and reduces panel space requirements.
Engineered with eddy current technology, the 330180-91-CN ensures reliable static and dynamic measurements on turbines, compressors, and fluid-film bearing machines. Its rugged A308 aluminum housing and compliance with API 670 (4th Edition) standards guarantee durability and accuracy in harsh industrial environments.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | 330180-91-CN |
| Series | 3300 XL 8 mm Proximity Transducer System |
| System Length | 9.0 meters (29.5 feet) |
| Mounting Type | DIN rail |
| Probe Compatibility | 3300 XL 8 mm, 3300 8 mm, 3300 5 mm probes |
| Extension Cable | Compatible with 3300 XL extension cables |
| Measurement Type | Eddy current-based displacement (position + vibration) |
| Output Signal | Voltage proportional to probe-to-target distance |
| Target Calibration | AISI 4140 steel |
| Temperature Range (Operating) | –51 °C to +100 °C (–60 °F to +212 °F) |
| Temperature Range (Storage) | –51 °C to +105 °C (–60 °F to +221 °F) |
| Temperature Stability | Meets API 670 standards |
| Electrical Isolation | Integrated isolator base, no extra isolator plate needed |
| RFI Immunity | High resistance to radio frequency interference |
| Material | A308 aluminum |
| Weight | 0.7 kg |
