GE IS200DSPXH1DBD / DSPXH1D | Digital Signal Processor Board
Manufacturer: GE Fanuc
-
Part Number: IS200DSPXH1DBD/DSPXH1D
Condition：New with Original Package
Product Type: Digital Signal Processor Board
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
GE IS200DSPXH1DBD / DSPXH1D | Digital Signal Processor Control Board
Product Overview
The GE IS200DSPXH1DBD, also known as DSPXH1D, is an advanced Digital Signal Processor (DSP) Control Board designed for Mark VI and EX2100 control systems. It executes real-time algorithms, processes high-speed analog and digital signals, and manages data acquisition from multiple field devices.
This board plays a vital role in turbine and generator control, ensuring accurate monitoring of gas turbines, steam turbines, and excitation systems. With its 32-bit floating-point processor, multi-channel input support, and 24-bit ADCs, the IS200DSPXH1DBD delivers exceptional computational accuracy and signal integrity for critical industrial applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Numbers | IS200DSPXH1DBD / DSPXH1D |
| Processor | 32-bit floating-point DSP |
| Analog Inputs | Up to 16 channels |
| Digital I/O | Up to 8 channels |
| ADC Resolution | 24-bit |
| Signal Filters | Anti-aliasing, configurable |
| Input Ranges | 4–20 mA / 0–10 VDC |
| Communication Ports | Ethernet, serial, ISBus |
| Firmware Storage | Flash memory |
| Operating Temperature | –40 °C to +70 °C |
| Dimensions | 178 mm × 102 mm × 254 mm |
| Mounting | Rack-mounted in control panel |
| Certifications | CE, UL, IEC-compliant |
FAQ
Q: Is the GE IS200DSPXH1DBD brand new and original?
A: Yes, all units are 100% brand new, original, and factory-sealed.
Q: Do you keep stock for IS200DSPXH1DBD / DSPXH1D?
A: Yes, we maintain ready inventory to ensure fast shipping.
Q: How fast can you ship after order confirmation?
A: We typically ship within 3 days to 2 weeks, depending on order size and logistics.
Q: Which couriers are available for delivery?
A: We commonly use DHL, FedEx, or UPS, based on customer location.
Q: What if the board has a technical defect?
A: We support returns within 30 days for any verified quality issues.
Q: Does the IS200DSPXH1DBD support software configuration?
A: Yes, it supports configuration via Toolbox or Unit Data Highway.
Q: Can it operate in extreme conditions?
A: Yes, the board functions reliably between –40 °C and +70 °C.
