Honeywell TC-RPSCA2 Redundant Power Supply Chassis Adapter
The Honeywell TC-RPSCA2 is a critical accessory designed for Honeywell's C200 and C300 Distributed Control Systems (DCS). This redundant power supply chassis adapter allows the installation of two power supplies within a single chassis, ensuring system reliability and minimizing the risk of downtime. In applications where system uptime is crucial, the TC-RPSCA2 guarantees continuous power availability by maintaining power even if the primary power supply fails.

Mounted on the left side of the chassis, the TC-RPSCA2 does not consume valuable module slots, preserving space for I/O or controller modules. It is compatible with a range of Honeywell chassis models, including TC-FXX042, TC-FXX072, TC-FXX102, TK-FXX102, TC-FXX132, TK-TXX132, and TC-FXX172.

Technical Specifications

• Model Number: TC-RPSCA2

• Product Type: Redundant Power Supply Chassis Adapter

• Power Ratings:

• 15A @ 5.1VDC

• 1.5A @ 1.2VDC

• 2.8A @ 24VDC

• 4A @ 3.3VDC

• Mounting Location: Left side of chassis (does not occupy a module slot)

• Compatible Chassis: TC-FXX042, TC-FXX072, TC-FXX102, TK-FXX102, TC-FXX132, TK-TXX132, TC-FXX172

• Dimensions (L × D × H): 3.4 × 14.4 × 15.0 cm (1.34 × 5.67 × 5.91 in)

• Weight: 0.228 kg (0.50 lb)

• Country of Origin: USA

• Condition: New

FAQ

• Q: What is the primary function of the TC-RPSCA2?
  A: The TC-RPSCA2 is a redundant power supply chassis adapter that allows the installation of dual power supplies in Honeywell DCS systems, ensuring uninterrupted power in case of a failure.

• Q: Does the TC-RPSCA2 take up space in the chassis?
  A: No, it mounts on the left side of the chassis without consuming any module slots, leaving space for I/O or controller modules.

• Q: Which Honeywell chassis models are compatible with the TC-RPSCA2?
  A: The TC-RPSCA2 is compatible with multiple Honeywell chassis models, including TC-FXX042, TC-FXX072, TC-FXX102, TK-FXX102, TC-FXX132, TK-TXX132, and TC-FXX172.

• Q: What power supply ratings are supported by the TC-RPSCA2?
  A: The TC-RPSCA2 supports the following ratings: 15A at 5.1VDC, 1.5A at 1.2VDC, 2.8A at 24VDC, and 4A at 3.3VDC.

• Q: Is the TC-RPSCA2 suitable for mission-critical applications?
  A: Yes, the TC-RPSCA2 is designed for mission-critical systems where redundancy and fault tolerance are essential to ensure high system uptime.
