GE Fanuc IC697CPX935-HE | High-Speed CPU for Automation
Manufacturer: GE Fanuc
-
Part Number: IC697CPX935-HE
Condition：New with Original Package
Product Type: High-Speed CPU for Automation
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The GE Fanuc IC697CPX935-HE is a single-slot CPU module designed for the Series 90-70 PLC platform, delivering precise real-time control for industrial automation systems. It efficiently manages complex processes, machine operations, and material handling in sectors including energy, metals, and manufacturing.
Equipped with a 96 MHz 80486DX4 microprocessor, the IC697CPX935-HE executes floating-point operations at 0.4 microseconds per instruction, ensuring high-speed and reliable control performance. The module features 1 MB of battery-backed RAM for secure program storage and 256 KB of flash memory for non-volatile data retention.
Supporting up to 12,000 discrete I/O points and 8,000 analog I/O points, this CPU communicates with I/O and smart option modules through a VME C.1 standard backplane. It also includes three serial ports (1 RS232, 2 RS485) and supports SNP slave mode, enabling flexible integration with optional Ethernet, USB, or link interface modules.
Its compact single-slot form factor allows easy installation in rack-mounted systems, while the robust design ensures stable performance in industrial environments. Moreover, the IC697CPX935-HE provides reliable operation across a temperature range of –10°C to +55°C, with a fan required above 50°C.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | IC697CPX935-HE |
| Manufacturer | GE Fanuc Emerson |
| Series | Series 90-70 PLC |
| Processor | 80486DX4, 96 MHz |
| Floating Point Speed | 0.4 µs per operation |
| User Memory | 1 MB battery-backed RAM |
| Flash Memory | 256 KB |
| I/O Capacity | 12K discrete I/O, 8K analog I/O |
| Serial Ports | 1 × RS232, 2 × RS485 |
| Communication Protocols | SNP slave mode, Ethernet, USB, link interface (optional) |
| Programming Platforms | MS-DOS, Windows NT/95 |
| Operating Temperature | –10°C to +55°C (fan required above 50°C) |
| Mounting Type | Single-slot rack mount |
| Backplane Interface | VME C.1 standard |
| Current Required | 3.1 Amps |
| Voltage Input | 5 VDC |
| Condition | New or refurbished |
FAQ
Q1: What is the processor speed of IC697CPX935-HE?
A1: It runs at 96 MHz and executes floating-point instructions at 0.4 microseconds per operation.
Q2: How much memory is included?
A2: It includes 1 MB battery-backed RAM and 256 KB flash memory for secure storage.
Q3: What I/O capacity does it support?
A3: Supports 12,000 discrete and 8,000 analog I/O points for large-scale automation.
Q4: Which communication interfaces are available?
A4: It includes 1 RS232 and 2 RS485 serial ports, with optional Ethernet, USB, or link modules.
Q5: Is it suitable for harsh industrial environments?
A5: Yes, it operates reliably from –10°C to +55°C and provides stable PLC control.
