Product Description – Schneider STBXSP3010 Power Supply Module

The Schneider STBXSP3010 is a robust Power Supply Module (PSM) within the Modicon Advantys STB distributed I/O range. It provides regulated 24 V DC field power and 5 V DC logic power to STB islands, ensuring reliable operation of all connected input and output modules. Moreover, it offers galvanic isolation between input and output circuits, protecting both the STB backplane and downstream field devices from electrical faults. Therefore, this module is essential for industrial automation, machine control, and process monitoring applications.

Its compact DIN-rail design allows easy integration into STB islands, supporting hot-swappable installation for minimal downtime. In addition, LED indicators provide instant diagnostics of logic and field power status, helping technicians quickly identify and resolve any issues. Its durable construction and IP20 protection rating make it suitable for a wide range of industrial environments.

Technical Specifications

Electrical Characteristics

• Input Voltage: 24 V DC nominal

• Voltage Range: 19.2–30 V DC

• Output Voltage (Logic): 5 V DC, up to 1.2 A

• Output Voltage (Field): 24 V DC, up to 8 A

• Isolation: Galvanic isolation between input and output

• Protection: Overload, short-circuit, undervoltage detection

Interface & Connection

• Backplane Connection: Supplies STB island bus via integrated connector

• Field Wiring: Removable terminal block for 24 V DC devices

• Diagnostics: LED indicators for logic/field power and faults

Mechanical

• Mounting: DIN-rail (part of STB island)

• Dimensions (W × H × D): 128.3 × 18.4 × 70 mm

• Weight: 0.4 kg

Environmental & Compliance

• Operating Temperature: 0–60 °C

• Storage Temperature: −40–85 °C

• Relative Humidity: 5–95% non-condensing

• Protection Rating: IP20

• Certifications: CE, UL, CSA

• Sustainability: RoHS and REACh compliant

FAQ

Q1: What voltages does the STBXSP3010 supply?
It provides 24 V DC for field devices and 5 V DC for STB logic bus.

Q2: Can this module be hot-swapped?
Yes, it supports hot-swappable installation for minimal operational downtime.

Q3: What protection features are included?
Overload, short-circuit, and undervoltage protection are built-in.

Q4: What is the maximum current for the field supply?
It can supply up to 8 A for sensors, actuators, and other devices.

Q5: Is it compatible with all STB I/O modules?
Yes, it is designed to power all distributed I/O modules within an STB island.
