ADV151-P00/D5A00 | Yokogawa Input Module for ProSafe-RS

Product Description

The Yokogawa ADV151-P00/D5A00 is a digital input module designed for use in CENTUM VP and ProSafe-RS control and safety systems. It efficiently gathers discrete input signals from field devices such as push buttons, limit switches, and relays. These signals are then processed to perform interlocking, monitoring, and logic control functions critical to plant operations.

Each of the 16 input channels supports dry contact or 24 VDC signals and features built-in optical isolation to protect against electrical noise and ground loops. Moreover, the module’s robust design ensures high reliability even under harsh environmental conditions, making it suitable for long-term industrial deployment.

The D5A00 suffix indicates a hardware variant optimized for compatibility with Yokogawa’s latest I/O subsystems. Therefore, it provides seamless integration within existing CENTUM VP and ProSafe-RS architectures. In addition, diagnostic features such as open- and short-circuit detection help maintain operational safety and simplify maintenance.

 Technical Specifications

• Model Number: ADV151-P00/D5A00

• Product Type: Digital Input Module

• Input Channels: 16 channels

• Input Type: Dry contact or 24 VDC digital signal

• Input Voltage Range: 18 VDC to 30 VDC

• Input Current: ≤ 4 mA per channel

• Response Time: ≤ 10 ms typical

• Signal Isolation: Optical isolation between input and internal bus

• Diagnostic Features: Open circuit, short circuit, contact bounce suppression

• Internal Bus Interface: Vnet/IP via node unit

• Power Supply: System powered (typical 5 VDC logic level)

• Power Consumption: 3.5 W

• Mounting Type: Rack-mounted (FCS/ProSafe-RS backplane)

• Dimensions: 107.5 mm × 130 mm × 32.8 mm

• Weight: 0.3 kg

• Country of Origin: Japan

 FAQ

Q1: What is the main function of the ADV151-P00/D5A00 module?
It collects discrete digital signals from field devices for monitoring and control purposes.

Q2: Which systems are compatible with this model?
It is compatible with Yokogawa CENTUM VP and ProSafe-RS systems.

Q3: Does it support dry contact inputs?
Yes, it supports both dry contact and 24 VDC digital signal inputs.

Q4: How many input channels does it include?
The module provides 16 isolated input channels.

Q5: What is the warranty period?
A 12-month warranty is provided with all new units.
