KJ3204X1-BA1 | Emerson DeltaV DO Module for Industrial Automation

Product Description

The Emerson VE4002S1T2B5 (KJ3204X1-BA1) is a Series 2 Discrete Output (DO) module designed for DeltaV™ distributed control systems. It provides 32 high-side 24 V DC outputs for reliable control of actuators, solenoids, relays, and other field devices in industrial automation.

Moreover, this module features rugged construction and hazardous area certifications (ATEX, IECEx, FM), ensuring safe operation in demanding environments. Each output channel includes LED indicators for real-time status monitoring, while channel isolation enhances system reliability.

In addition, advanced diagnostics allow early detection of faults, helping operators perform predictive maintenance efficiently. Its compact design facilitates easy installation in DeltaV carriers, supporting hot-swap functionality without process interruptions.

Technical Specifications

• Product Type: Discrete Output Module

• Model Number: KJ3204X1-BA1

• Order Code: VE4002S1T2B5

• Manufacturer: Emerson

• System: DeltaV™ Series 2 I/O

• Channels: 32 outputs

• Output Type: 24 V DC high-side

• Local Bus Power: 12 V DC at ~150 mA

• Field Power (per card): 24 V DC at ~3.2 A

• Field Power (per channel): 24 V DC at ~100 mA

• Operating Temperature: –40 °C to +70 °C

• Storage Temperature: –55 °C to +85 °C

• Shock Resistance: 10 g, ½ sinewave for 11 ms

• Vibration Resistance: 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz)

• Airborne Contaminants: ISA‑S71.04 Class G3

• Humidity: 5–95 % non-condensing

• Protection Rating: IP20

• Certifications: ATEX II 3G Ex nA IIC Gc, IECEx FMG, FM approvals

• Mounting: Compact card format for DeltaV carriers

• LED Indicators: Yes, for each channel

• Isolation Between Channels: Yes

• Weight: 0.2 kg

• Lifecycle: Active product, supported in DeltaV systems
