NFAI141-S01 Yokogawa | Compact Non-Isolated Input Module
Manufacturer: Yokogawa
-
Part Number: NFAI141-S01
Condition：New with Original Package
Product Type: Compact Non-Isolated Input Module
-
Country of Origin: Japan
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Yokogawa NFAI141-S01 is a high-density non-isolated analog input module designed for STARDOM FCN/FCJ autonomous controllers.
It provides 16 analog input channels for receiving signals from 2-wire or 4-wire transmitters.
This module is cost-effective and compact, ideal for applications where channel-to-channel isolation is not required.
It ensures reliable signal acquisition in industrial process monitoring and control systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | NFAI141-S01 |
| Product Type | Non-Isolated Analog Input Module |
| Compatible Controllers | STARDOM FCN/FCJ autonomous controllers |
| Number of Channels | 16 analog input channels |
| Supported Signal Types | 4–20 mA, 1–5 V DC |
| Isolation | Non-isolated (shared ground) |
| Input Current | 27 mA |
| Input Voltage | 22.8–26.4 V |
| Terminal Connection | Pressure clamp terminal (C3GC26270G) |
| Dimensions (W × H × D) | 2.5 cm × 12.7 cm × 12.7 cm |
| Weight | 0.44 lbs (≈ 0.2 kg) |
| Condition | New and original |
| Certifications | Certificate of Origin (COO), Test Report |
| Applications | Process monitoring, analog signal acquisition, compact control systems |
FAQs
Q1: How many analog input channels does the NFAI141-S01 support?
It supports up to 16 analog input channels for process monitoring.
Q2: Is channel-to-channel isolation provided?
No, this module is non-isolated with a shared ground design.
Q3: What signal types can it accept?
It accepts 4–20 mA and 1–5 V DC signals from transmitters.
Q4: What are the module’s dimensions and weight?
Dimensions are 2.5 cm × 12.7 cm × 12.7 cm, and weight is ≈ 0.2 kg.
Q5: Is the module compatible with STARDOM controllers?
Yes, it is compatible with STARDOM FCN and FCJ autonomous controllers.
