Product Description – Honeywell 054011-00 Universal Sensor Baseboard

The Honeywell 054011-00 Universal Sensor Baseboard is a critical interface module designed to integrate seamlessly into Honeywell Distributed Control Systems (DCS). It serves as a reliable mounting platform for various analog and digital sensor modules, bridging field devices with the control system.

Moreover, the baseboard ensures galvanic isolation and signal conditioning, protecting controllers from electrical noise while maintaining precise data acquisition. Its industrial-grade construction allows continuous operation in harsh environments, including petrochemical plants, power generation, and manufacturing facilities.

In addition, the compact form factor and standardized design make it easy to install in racks, cabinets, or other industrial enclosures. Certified under CE, UL, CSA, and TUV standards, it meets global industrial requirements for safety and reliability.

Technical Specifications

General Information

• Brand: Honeywell

• Model Number: 054011-00 / 05401100

• Type: Universal Sensor Baseboard

• System Compatibility: Honeywell Distributed Control Systems (DCS)

• Function: Mounting and electrical interface for sensor modules

• Country of Origin: USA

Electrical & Signal

• Power Supply: 24 VDC nominal

• Signal Isolation: Galvanic isolation between sensor and system bus

• Supported Sensors: Analog and digital (voltage, current, temperature, pressure)

Physical & Environmental

• Dimensions (H × W × D): 120 × 80 × 25 mm

• Weight: 0.5 kg

• Operating Temperature: –20 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5–95% RH, non-condensing

• Material: Industrial PCB with protective coating

• Certifications: CE, UL, CSA, TUV

FAQ

Q1: What types of sensors can be mounted on this baseboard?
A: Analog and digital sensors, including voltage, current, temperature, and pressure.

Q2: Does it provide electrical isolation for sensors?
A: Yes, galvanic isolation ensures system protection and reliable data acquisition.

Q3: Can it operate in harsh industrial conditions?
A: Yes, it is industrial-grade and withstands dust, vibration, and temperature extremes.

Q4: Which systems is it compatible with?
A: Honeywell Distributed Control Systems (DCS).

Q5: What certifications does this product have?
A: CE, UL, CSA, and TUV certifications for global industrial standards.
