10100/2/1 | Honeywell Horizontal Bus Driver with Low-Ripple Output
Manufacturer: Honeywell
-
Part Number: 10100/2/1
Condition：New with Original Package
Product Type: Horizontal Bus Driver with Low-Ripple Output
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The HONEYWELL 10100/2/1 is a horizontal bus driver module for Honeywell FSC/PLC and Experion/PKS systems. It drives and buffers the horizontal bus, providing regulated 5 V and 24 V supply distribution. The module ensures low‑ripple bus voltage and supervision of fail‑safe digital input modules. Its lightweight design and plug‑in form factor simplify integration into control racks, supporting reliable industrial communication between I/O assemblies and controllers.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | 10100/2/1 |
| Type | Horizontal bus driver / bus-driver module |
| Primary Functions | Provides regulated 5 Vdc and 24 Vdc distribution, bus buffering, and horizontal bus supervision |
| Power Requirements | 10100/2/1 + A1/A21 cable: 5 Vdc 35 mA; 10100/2/1 + A22 cable: 5 Vdc 65 mA |
| Input Current | Approx. 7 mA at 24 Vdc for bus sensing and logic functions |
| Ripple Content | < 50 mV p-p |
| Space Requirements | 4 TE × 3 HE (= 4 HP, 3U) |
| Mounting | Plug‑in horizontal bus card for FSC/PLC rack with keyed connector |
| Weight | 1.5 Kg |
| Environmental | Industrial operating temperature, humidity, and EMC standards per Honeywell module requirements |
| Applications | Drives and buffers horizontal bus in FSC/PLC and Experion/PKS systems; ensures reliable supply and fail‑safe operation |
| Manufacturer | Honeywell |
| Origin | USA |
