Product Overview

The FC-TDO-1624 (Model: FC-TDO-1624) is a high-performance 16-channel digital output module engineered for Honeywell Safety Manager®, Fail-Safe Controller (FSC), and Experion® SIS platforms. This module acts as the critical execution layer in safety-instrumented systems, converting low-level controller logic into robust 24V DC discrete signals to drive field actuators.

Designed for millisecond-precision switching, the FC-TDO-1624 (Part Number: FC-TDO-1624) is essential for managing solenoids, interposing relays, and motor contactors in high-consequence environments. Its architecture emphasizes galvanic isolation and fault tolerance, ensuring that electrical noise or field-side short circuits do not propagate back to the central logic solver. This module is a cornerstone for Emergency Shutdown (ESD) and Fire & Gas (F&G) logic execution in refineries, power plants, and offshore platforms.

Detailed Technical Specifications

The FC-TDO-1624 is built to the following professional industrial standards:

• Manufacturer: Honeywell (USA)

• Model Number: FC-TDO-1624

• Product Type: 16-Channel Digital Output Module

• System Compatibility: Safety Manager, FSC, Experion PKS

• Output Channels: 16 Independent discrete channels

• Nominal Output Voltage: 24 V DC

• Switching Response Time: ≤ 1 ms (High-speed actuation)

• Output Current: 0.5 A to 2.0 A per channel (dependent on system cooling and load type)

• Isolation Voltage: 1000 V AC (Channel-to-Ground)

• Protection Logic: Integrated short-circuit and thermal overload protection

• Operating Temperature: –40 °C to +85 °C (Extreme industrial range)

• Relative Humidity: 5 % to 95 % RH (non-condensing)

• Termination: Screw terminals for field wiring (up to 2.5 mm² / AWG 14)

• Physical Dimensions: 90 mm × 70 mm × 58 mm

• Weight: 0.3 kg (0.6 lbs)

• Mounting Configuration: DIN-rail or panel mount within I/O cabinets

• Compliance: SIL3 capable (within safety loop), CE, UL, CSA
