Foxboro FBM207C P0917MF – Product Description

Overview

The Foxboro FBM207C (P0917MF) is a 16-channel analog input module designed for the Foxboro I/A Series Distributed Control System (DCS). It accurately acquires 4–20 mA signals from field devices including transmitters and sensors. Moreover, the updated hardware and design revisions improve performance stability and module reliability, making it ideal for long-term industrial use.

This revision of the FBM207 family maintains full compatibility with Foxboro DCS systems while supporting redundant 24 VDC power supplies. Therefore, it ensures continuous operation in mission-critical applications where uptime and precise data acquisition are essential.

Technical Data

• Model: FBM207C P0917MF

• Type: Analog Input Module (4–20 mA)

• System Compatibility: Foxboro I/A Series DCS

• Number of Channels: 16 analog inputs

• Signal Range: 4–20 mA

• Resolution: 16-bit

• Accuracy: ±0.1% of full scale

• Isolation: Galvanic isolation between field and system

• Conversion Time: Configurable per channel

• Fail-Safe Options: Hold last value or return to preset value

• Input Voltage: 24 VDC (supports redundant supply)

• Power Consumption: 8.5 W per module

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5% – 95% non-condensing

• Dimensions (H × W × D): 14.7 × 5.15 × 11.4 cm

• Weight: 1.1 kg

• Country of Origin: USA

FAQ

1. What improvements distinguish the FBM207C P0917MF from earlier versions?
It offers updated hardware, improved reliability, and enhanced performance stability.

2. How many channels does this module support?
It supports 16 isolated analog input channels.

3. Does it work with all Foxboro I/A Series systems?
Yes, it is fully compatible with the Foxboro I/A Series DCS.

4. What fail-safe options are available?
You can hold the last value or return to a preset value in case of failure.

5. Which industries commonly use this module?
It is used in oil and gas, chemicals, refining, power generation, and water treatment facilities.
