1606-XLDNET4 Compact DIN-Rail Supply | Allen-Bradley NET Series

Product Description

Product Overview

1606-XLDNET4 is an Allen-Bradley (Rockwell Automation) Bulletin 1606 XLD NET series compact DIN-rail power supply, designed to deliver 24 V DC at 4 A (96 W) for automation and control systems.

This NET series model includes built-in N+1 redundancy and monitoring features, making it suitable for EtherNet/IP and DeviceNet applications. Its compact footprint allows installation in tight control cabinets while maintaining high efficiency (~88%) and robust performance.

Technical Specifications

Model / Catalog Number: 1606-XLDNET4
Series: Bulletin 1606 XLD NET

• Rated Power: 96 W

• Output Voltage: 24 V DC

• Output Current: 4 A

• Input Voltage (AC): 85–264 V AC, 47–63 Hz (switchable 120/230 V AC)

• Input Voltage (DC): 90–150 V DC (210–375 V DC option)

• Efficiency: 88%

• Redundancy: N+1 redundancy capability (NET series feature)

• Relay Contact: “RDY” for monitoring output status

• Operating Temperature: –25 °C to +70 °C (derating above +60 °C)

• Mounting: DIN-rail, quick installation

• Dimensions (L×W×H): 124 × 124 × 60 mm

• Weight: 0.6 kg

• Certifications: UL, cULus, CE, ATEX, SEMI F47, NEC Class 2, Class I Div. 2 (Hazardous Locations)

• Status: Discontinued by manufacturer; replaced by 1606-XLSDNET4
