1715-0F8I ControlLogix Analog Output | Allen-Bradley 8 Pt
Manufacturer: ABB
-
Part Number: 1715-0F8I
Condition：New with Original Package
Product Type: ControlLogix Analog Output Module
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
Product Overview
The 1715-0F8I from Allen-Bradley (Rockwell Automation) is an 8-point analog output module for the Bulletin 1715 Redundant I/O platform, designed for ControlLogix SIS (Safety Instrumented Systems) and other critical process control applications.
It provides 8 isolated analog output channels, capable of delivering 4–20 mA or 0–10 V signals to field devices such as control valves, actuators, and variable frequency drives (VFDs). When paired with a 1715 redundant base/adapter, it supports fully redundant operation, ensuring continuous operation even during module faults.
Key features include hot-swap capability, internal diagnostics, automatic IP switchover on fault, and channel-to-channel isolation for enhanced reliability. The module is engineered for industrial environments requiring high accuracy, stability, and fault tolerance.
Technical Specifications
| Parameter | Details |
|---|---|
| Catalog Number | 1715-0F8I |
| Series | Bulletin 1715 Redundant I/O |
| Module Type | ControlLogix Analog Output Module |
| Number of Outputs | 8 channels |
| Output Signal | 4–20 mA DC, single-ended, isolated / 0–10 V |
| Accuracy | ±0.30% + 10 µA at 40 °C |
| Temperature Drift | (0.01% + 0.1 µA)/°C |
| Isolation | Channel-to-channel and channel-to-system |
| Input Power | 18–32 V DC, 3.6 W |
| Wiring | 22–16 AWG shielded wire |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | –40 °C to 85 °C (–40 °F to 185 °F) |
| Humidity | 5–95% non-condensing |
| Dimensions (W×H×D) | 120 × 130 × 50 mm (4.72 × 5.12 × 1.97 in) |
| Weight | 0.5 kg (1.1 lbs) |
| Mounting Type | Panel Mount |
| Communication | ControlLogix Backplane |
| Protection Rating | IP20 (cabinet required) |
| Certifications | UL, CE, CSA, ATEX (for safety applications) |
