1783-BMS20CGP AB Stratix 5700 | Managed Industrial Switch
Manufacturer: ABB
-
Part Number: 1783-BMS20CDP
Condition：New with Original Package
Product Type: Managed Industrial Switch
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Allen-Bradley 1783-BMS20CGP | Stratix 5700 Managed Ethernet Switch
Product Overview
The Allen-Bradley 1783-BMS20CGP is a Stratix 5700 industrial managed Ethernet switch designed by Rockwell Automation for high-performance and secure network communication. It supports 20 total ports, including 16 RJ45 copper Ethernet ports and 4 fiber optic ports, providing excellent flexibility for mixed media networks.
Built for industrial control and automation, the 1783-BMS20CGP ensures network reliability with Device Level Ring (DLR) and Rapid Spanning Tree Protocol (RSTP) redundancy features. Its IP30-rated metal housing and DIN-rail mounting make it perfect for rugged environments in manufacturing, energy, and process automation.
This managed switch simplifies network management through a web-based GUI, command-line interface (CLI), and standard SNMP protocols, ensuring consistent performance and scalability across connected devices.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | 1783-BMS20CGP |
| Series | Stratix 5700 |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Type | Managed Industrial Ethernet Switch |
| Total Ports | 20 ports |
| Port Configuration | 16 × RJ45 copper, 4 × fiber optic |
| Redundancy Support | Device Level Ring (DLR), STP, Rapid STP |
| Management Features | VLAN, QoS, IGMP snooping, SNMP, Web GUI, CLI |
| Power Supply | Dual redundant DC inputs |
| Mounting Type | DIN rail |
| Enclosure Rating | IP30 (industrial-grade metal housing) |
| Operating Temperature | –40°C to +60°C |
| Certifications | UL, CE, CSA, RoHS, ATEX |
| Lifecycle Status | Active |
| Condition | Brand new, factory sealed |
| Country of Origin | USA |
| Applications | Industrial Ethernet, SCADA, PLC networks, machine control |
FAQ
Q1: How many total ports does the 1783-BMS20CGP provide?
A1: The switch includes 20 ports — 16 copper (RJ45) and 4 fiber optic interfaces.
Q2: What redundancy features are supported?
A2: It supports Device Level Ring (DLR), Spanning Tree Protocol (STP), and Rapid STP for robust network reliability.
Q3: What management options are available?
A3: You can manage it through a web-based GUI, CLI, or SNMP, ensuring flexibility for network administrators.
Q4: What is the enclosure rating?
A4: The 1783-BMS20CGP features an IP30-rated metal housing suitable for industrial environments.
Q5: What are the power requirements?
A5: It operates using redundant DC power inputs, ensuring uninterrupted operation.
