1KHL178012R0001M | ABB Substation Display & Control Unit
Manufacturer: ABB
-
Part Number: 1KHL178012R0001M
Condition：New with Original Package
Product Type: Substation Display & Control Unit
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
ABB 1KHL178012R0001M Display and Control Module
Overview
The ABB 1KHL178012R0001M is a high-performance display and control module designed for ABB protection relays, including the REC650 and REB650 series.
It provides a graphical interface for real-time data visualization, system diagnostics, and configuration, supporting efficient substation and industrial automation operations.
The module operates reliably in harsh environments, with a wide operating temperature range and humidity tolerance.
Its compact 100 mm × 100 mm × 50 mm form factor and 0.5 kg weight make installation in control panels simple and space-efficient.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | 1KHL178012R0001M |
| Product Type | Display and Control Module |
| Display Type | High-resolution graphical interface |
| Display Size | 4.3 inches |
| Resolution | Estimated 480 × 272 pixels |
| Power Supply | 24 V DC (estimated) |
| Humidity Range | 5% to 95%, non-condensing |
| Operating Temperature | –20°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions (L × W × H) | 100 mm × 100 mm × 50 mm |
| Weight | 0.5 kg |
| Country of Origin | Switzerland |
| Application Areas | Substation automation, protection relay interface, industrial control |
FAQs
Q1: What devices is the ABB 1KHL178012R0001M compatible with?
✅ It is primarily compatible with ABB REC650 and REB650 protection relays.
Q2: What is the display size of this module?
✅ The 1KHL178012R0001M features a 4.3-inch high-resolution graphical display.
Q3: Can it operate in harsh environments?
✅ Yes, it supports –20°C to +60°C operating temperature and 5–95% non-condensing humidity.
Q4: Is this module original and brand new?
✅ Yes, the ABB 1KHL178012R0001M is factory-new and original, with a standard warranty.
Q5: What are the mounting options for this display unit?
✅ Its compact form factor allows for easy panel integration in control and automation systems.
