1SAP140200R0201 PM582 ABB AC500 PLC Controller Unit

Product Overview

The PM582 (1SAP140200R0201) is a mid-range Central Processing Unit (CPU) within the ABB AC500 PLC platform, specifically engineered for applications requiring a balance of logic processing and advanced power monitoring. Featuring 512KB of user memory, this module provides the computational power necessary for complex automation tasks while functioning as a high-precision measurement hub for electrical networks. The PM582 (1SAP140200R0201) is optimized for real-time monitoring of critical electrical parameters, including harmonics and power quality, making it a cornerstone for industrial energy management and substation automation systems. Its compact, modular architecture allows it to serve as the intelligent core for distributed control systems (DCS) and SCADA-integrated environments.

Detailed Technical Specifications

• Manufacturer: ABB

• Model Designation: PM582

• Order Number: 1SAP140200R0201

• Series: AC500 / PM500 Measurement Series

• Device Category: Central Processing Unit (CPU) / Power Measurement Module

• User Memory: 512 KB (Program and Data storage)

• Measurement Accuracy: Typically Class 0.2 for voltage and current acquisition

• Measured Parameters: Voltage, current, active/reactive/apparent power, energy (kWh/kVARh), frequency, power factor, and THD (Total Harmonic Distortion)

• Communication Protocols: Modbus RTU/TCP, DNP3, IEC 61850, and Profibus (expansion module dependent)

• Processing Speed: High-speed logic execution for industrial automation

• Power Supply Input: 24 V DC (Standard version)

• Operating Temperature: -20°C to +60°C (-4°F to +140°F)

• Storage Temperature: -40°C to +85°C (-40°F to +185°F)

• Mounting Configuration: DIN-rail via compatible Terminal Base

• Housing Material: Industrial-grade reinforced structural plastic

• Dimensions: 160 mm × 120 mm × 90 mm (Approx. system footprint)

• Net Weight: 1.5 kg

• Ingress Protection: IP20

• Compliance: CE, UL, RoHS compliant
