3481 Triconex AO Module | SIL 3 Analog Output for Industrial SIS

Product Description

Overview

The Triconex AO3481 is a high-integrity analog output module designed for precise control of field devices within Triconex Safety Instrumented Systems (SIS).
It provides accurate current or voltage output signals to actuators, valves, and other critical equipment.
Moreover, the module employs Triple Modular Redundancy (TMR) architecture, ensuring continuous operation even if hardware faults occur.
With SIL 3 certification, it is ideal for Emergency Shutdown (ESD), Fire & Gas (F&G), Burner Management Systems (BMS), and High-Integrity Pressure Protection Systems (HIPPS).

Technical Specifications

• Product Type: Analog Output Module (AO)

• Model Number: 3481 / AO3481

• Manufacturer: Schneider Electric (Triconex brand)

• System Compatibility: Triconex SIS (Tricon/Trident platforms)

• Architecture: Triple Modular Redundancy (TMR)

• Number of Channels: Typically 8 isolated analog output channels

• Output Signal Types: Configurable: 4–20 mA DC, 0–5 VDC, 1–5 VDC

• Resolution: 12–16 bit D/A conversion

• Accuracy: ±0.1% of span typical

• Isolation: Channel-to-channel and channel-to-system isolation

• Safety Integrity Level: SIL 3 compliant

• Diagnostics: Built-in self-diagnostics, fault detection, redundancy monitoring

• Operating Temperature: –20 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5–95% RH

• Dimensions (H × W × D): 187 × 114 × 25 mm

• Weight: 1.6 kg

• Certifications: UL, ATEX, IECEx, CE

FAQ

Q1: How many output channels does the Triconex AO3481 support?
It typically supports 8 isolated analog output channels configurable for voltage or current signals.

Q2: What signal types are supported by the AO3481?
The module supports 4–20 mA DC, 0–5 VDC, and 1–5 VDC outputs for field devices.

Q3: Is the module suitable for safety-critical applications?
Yes, it is SIL 3 certified and compatible with ESD, F&G, BMS, and HIPPS applications.

Q4: Does the module include diagnostics?
Yes, it has built-in self-diagnostics, fault detection, and redundancy monitoring to enhance reliability.

Q5: Can the AO3481 operate in harsh industrial environments?
Moreover, it is designed to operate reliably under extreme temperature, humidity, and industrial conditions.
