3500/02 | Bently Nevada System Architecture & Rack Configuration
Manufacturer: Bently Nevada
-
Part Number: 3500-02
Condition：New with Original Package
Product Type: System Architecture & Rack Configuration
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Bently Nevada 3500/02 is a system rack designed to house all modules of the 3500 Series Machinery Protection System. It provides a robust mechanical and electrical framework for monitoring vibration, position, temperature, and speed in critical rotating machinery.
This rack supports hot-swappable modules, redundant power supplies, and high-speed communication backplanes, enabling reliable system integration with control networks. Available in 14-slot standard or 7-slot mini rack configurations, it adapts to diverse industrial applications.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 3500/02 |
| Function | System rack for 3500 Series modules |
| Rack Sizes | 14-slot (standard), 7-slot (mini rack) |
| Mounting Options | Panel mount or rack mount (EIA standard 19-inch) |
| Power Supply Support | Supports up to two 3500/15 power supplies for redundancy |
| Module Compatibility | Accepts all 3500 Series monitoring and communication modules |
| Backplane | High-speed data bus for module communication |
| Operating Temperature | –30°C to +65°C |
| Dimensions | 14-slot rack approx. 483 × 267 × 267 mm; varies by slot count |
| Weight | 0.8 kg |
| Environmental Rating | Industrial-grade; suitable for harsh environments |
| Applications | Turbines, compressors, pumps, motors, and other critical rotating machinery |
FAQ
Q1: How many slots does the 3500/02 rack support?
A1: It supports 14-slot standard or 7-slot mini rack configurations depending on system needs.
Q2: What power supplies are compatible?
A2: The rack supports up to two 3500/15 power supplies for redundancy.
Q3: Can modules be replaced without downtime?
A3: Yes, it supports hot-swappable modules to ensure continuous monitoring.
Q4: Which modules are compatible with this rack?
A4: It accepts all 3500 Series monitoring and communication modules.
Q5: What is the operating temperature range?
A5: The rack is rated for –30°C to +65°C, suitable for harsh industrial environments.
