369-HI-R-M-0-P-0-E GE | High-Integration Motor Management Relay

Product Description

The GE Multilin 369-HI-R-M-0-P-0-E is a high-performance motor management relay engineered for medium voltage AC motors. It delivers comprehensive protection by monitoring electrical and mechanical parameters while detecting abnormal conditions and triggering rapid protective actions. Moreover, the relay features adaptive learning to adjust automatically to motor characteristics, optimizing safety and performance. In addition, enhanced diagnostics with an upgraded front-panel display provide detailed motor health reports, waveform captures, and event logging for predictive maintenance. The robust, flame-retardant enclosure with conformal coating ensures reliable operation in harsh industrial environments, including high humidity, dust, and corrosive conditions.

Technical Specifications

Manufacturer: GE Multilin (GE Grid Solutions)
Model Number: 369-HI-R-M-0-P-0-E
Series: 369 Motor Management Relay
Function: Motor protection, metering, diagnostics, and event recording

Control Power Input Range:

• 110–250 VDC

• 100–240 VAC, 50/60 Hz

Power Consumption: Nominal 20 VA; Maximum 65 VA
Fuse Protection: 3.15 A, 250 V

Inputs/Outputs:

• 6 optically isolated digital/switch inputs

• Multiple relay outputs for trip, alarm, and control functions

Event Recording & Diagnostics:

• Pre-trip alarms and waveform capture

• Motor health reports and fault logging (overloads, phase imbalance, ground faults, locked rotor)

Display: Enhanced front-panel display version
Operating Temperature: –40 °C to +60 °C
Storage Temperature: –40 °C to +80 °C
Humidity: Up to 95% non-condensing

Dimensions: 11.5 in (H) × 5.5 in (W) × 8.5 in (L)
Weight: 4.5 kg (10 lbs)
Enclosure: Flame-retardant, corrosion-resistant with conformal coating

FAQ

Q: What motor sizes does the 369-HI-R-M-0-P-0-E support?
It is designed for medium voltage AC motors with full protection features.

Q: Which communications protocols are supported?
The relay supports RS232 and RS485 communication ports.

Q: Does it provide motor health reporting?
Yes, it captures waveform data, fault logs, and generates motor health reports.

Q: What is the operating temperature range?
The relay operates between –40 °C and +60 °C.

Q: Is the enclosure suitable for harsh industrial environments?
Yes, it is flame-retardant, corrosion-resistant, and coated to withstand dust and humidity.
