4000056‑002 Triconex Digital Input Module | Safety Instrumented

Product Description

Overview

The Triconex 4000056‑002 is a high-performance digital input module designed for safety-critical industrial applications.
It acquires discrete signals from field devices including limit switches, pushbuttons, sensors, and contact closures.
Moreover, its Triple Modular Redundancy (TMR) architecture ensures continuous operation even if a channel experiences hardware failure.
Certified to SIL 3, the module is ideal for Emergency Shutdown (ESD), Fire & Gas (F&G), Burner Management Systems (BMS), and High-Integrity Pressure Protection Systems (HIPPS).
The module is built to withstand harsh industrial environments, providing reliable signal acquisition with high noise immunity.

Technical Specifications

• Product Type: Digital Input Module

• Model Number: 4000056‑002

• Manufacturer: Schneider Electric (Invensys Triconex)

• System Compatibility: Triconex SIS (Tricon/Trident platforms)

• Architecture: Triple Modular Redundancy (TMR)

• Number of Channels: 32 independent digital input channels

• Input Signal Types: Dry contact, source/sink signals

• Input Voltage Range: Compatible with 24 VDC or 120 VAC

• Resolution: Digital (on/off) with high noise immunity

• Accuracy: ±0.1% typical for signal detection

• Isolation: Channel-to-channel and channel-to-system isolation

• Diagnostics: Built-in self-diagnostics, short/open circuit detection

• Communication Protocols: Modbus TCP, Ethernet/IP, PROFIBUS, OPC UA

• Operating Temperature: –20 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5–95% RH (non-condensing)

• Protection: IP20, EMI and vibration resistant

• Dimensions (H × W × D): 187 × 114 × 25 mm

• Weight: 0.8 kg

• Certifications: CE, UL, ATEX, IECEx

FAQ

Q1: How many channels does the Triconex 4000056‑002 support?
It provides 32 independent digital input channels for reliable monitoring of field devices.

Q2: What types of input signals are compatible?
The module supports dry contact and source/sink signals compatible with 24 VDC or 120 VAC.

Q3: Is it suitable for safety-critical applications?
Yes, it is SIL 3 certified and compatible with ESD, F&G, BMS, and HIPPS systems.

Q4: Does the module include diagnostics?
Yes, it includes real-time detection of short circuits, open circuits, and hardware faults.

Q5: Can it operate in harsh industrial environments?
Moreover, the module is industrial-grade, resistant to EMI, vibration, and temperature extremes.
