51400604-100 Honeywell | TDC 3000 System Chassis 5-Slot

Product Overview

The 51400604-100 (Model: 51400604-100) is a compact 5-slot module rack chassis designed specifically for the Honeywell TDC 3000 and TotalPlant Solution (TPS) Distributed Control Systems (DCS). This chassis serves as a fundamental hardware housing, providing the physical infrastructure and high-speed backplane connectivity required for various system modules, including Process Managers (PM), Advanced Process Managers (APM), and specialized interface cards.

Engineered for high-integrity industrial automation, the 51400604-100 (Part Number: 51400604-100) ensures deterministic signal distribution and stable power routing across its five universal slots. This chassis is a critical component in smaller-scale process units or distributed control nodes within oil refineries, chemical plants, and power generation facilities, where space efficiency and high availability are paramount. Its robust backplane architecture supports the expertise and reliability standards demanded by legacy Honeywell DCS environments.

Detailed Technical Specifications

The 51400604-100 provides a reliable foundation for module-to-backplane integration.

• Manufacturer: Honeywell

• Model Number: 51400604-100

• Product Type: 5-Slot Module Rack / Chassis File

• System Compatibility: Honeywell TDC 3000, TPS, PM, and APM systems

• Slot Capacity: 5 Universal Module Slots

• Backplane Function: Data bus and power distribution for installed modules

• Mounting Configuration: Rack-mounted (Standard 19-inch industrial cabinet) or Panel-mounted

• Power Supply: Fed via system power cables to the backplane (typically +5V, +12V DC rails)

• Connectivity: Integrated multi-pin backplane connectors for secure module mating

• Material: Industrial-grade heavy-duty metal construction for EMI/RFI shielding

• Operating Temperature: 0°C to +60°C (32°F to 140°F)

• Storage Temperature: -40°C to +85°C

• Operating Humidity: 5% to 95% RH (Non-condensing)

• Compliance: Industrial EMC and safety standards for process control equipment
