5SHX2645L0006 ABB IGCT Module | High-Power Converter Device
Manufacturer: ABB
-
Part Number: 5SHX2645L0006 3BHB012961R0002
Condition：New with Original Package
Product Type: High-Power Converter Device
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The ABB 5SHX2645L0006 (3BHB012961R0002) IGCT RC Module is a high-performance power semiconductor device designed for demanding industrial applications. It integrates an Integrated Gate-Commutated Thyristor (IGCT), gate unit, and reverse-conducting diode into a single compact module, enabling fast switching, high current conduction, and thermal stability. Moreover, its asymmetric design allows current conduction in one direction while blocking reverse voltage, making it ideal for medium-voltage converter topologies.
This module is suitable for high-power industrial drives, traction systems, and power converters, where precision and reliability are critical. In addition, its robust construction ensures durability under rigorous operating conditions, while conduction or forced-air cooling adapts to diverse system requirements.
Engineered for both performance and integration, the 5SHX2645L0006 ensures efficient operation in inverters, choppers, and industrial motor control systems, contributing to optimized energy handling and reduced system losses.
Technical Specifications
| Attribute | Specification |
|---|---|
| Model | 5SHX2645L0006 |
| Part Number | 3BHB012961R0002 |
| Device Type | Asymmetric IGCT RC Module |
| Core Technology | IGCT (Integrated Gate-Commutated Thyristor) |
| Voltage Rating | Up to 2600 V (estimated from model code) |
| Current Rating | 4500 A (estimated from model code) |
| Dimensions | 200 mm × 120 mm × 50 mm |
| Weight | 2.9 kg |
| Cooling Method | Conduction or forced air (application-dependent) |
| Application Areas | Medium-voltage drives, power converters, traction, industrial motor control |
| Country of Origin | Switzerland |
FAQ
Q1: What is the primary function of this IGCT module?
A1: It provides high-speed switching and current control in medium-voltage converter systems.
Q2: Can this module be used in traction applications?
A2: Yes, it is suitable for traction systems and industrial motor drives.
Q3: What cooling methods are supported?
A3: Conduction or forced-air cooling, depending on system requirements.
Q4: What does the “asymmetric” designation mean?
A4: It conducts current in one direction and blocks reverse voltage for safety and efficiency.
Q5: Is the voltage and current rating fixed?
A5: Voltage and current are estimated from the model code; consult the official datasheet for precise ratings.
