Foxboro 6077D1-9XYZDL Base/Processor Module – Product Description

Description / Overview

The Foxboro 6077D1-9XYZDL is a versatile base and processor module for the I/A Series Distributed Control System (DCS). It integrates data acquisition, signal processing, and communication interfaces to enable robust process automation. Moreover, it supports both single-processor and fault-tolerant dual-processor configurations, ensuring continuous operation even during hardware failures. Therefore, this module is ideal for industries where high reliability and 24/7 operation are essential.

Technical Data / Specifications

• Model: 6077D1-9XYZDL

• Type: I/A Series Base Module / Processor Control Module

• System Compatibility: Foxboro I/A Series DCS

• Memory: 16 MB SDRAM, 32 MB Flash

• Input Voltage: 24 VDC (supports redundant supply)

• Power Consumption: 8.5 W per non-fault-tolerant module

• Configuration: Single processor; dual modules for fault-tolerant operation

• Architecture: Distributed, supports field-mounted controllers

• Operating Temperature: 0 °C to +60 °C (32 °F to 140 °F)

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5% – 95% non-condensing

• Protection Class: Industrial enclosure

• Weight: 3.0 kg

• Country of Origin: USA

FAQ

Q1: Does this module support fault-tolerant operation?
Yes. Two modules can operate in parallel to provide uninterrupted operation.

Q2: What voltage does the 6077D1-9XYZDL require?
It operates on 24 VDC and supports redundant power supply.

Q3: Can it handle both analog and discrete signals?
Yes, it supports a wide range of input/output signals for versatile applications.

Q4: Which industries typically use this module?
Oil & gas, chemical, refining, power generation, pulp & paper, and mining.

Q5: What is the operating temperature range?
The module operates safely from 0 °C to +60 °C and can be stored from –40 °C to +85 °C.
