6ED1052-1FB00-0BA6 | Siemens | LOGO! 230RC Relay Output

Product Description

Control Intelligence Overview

The LOGO! 230RC (Part Number: 6ED1052-1FB00-0BA6) is a versatile logic module engineered by Siemens for small-scale automation tasks. Integrating a controller, operator display, and power supply into a single compact unit, the LOGO! 230RC (Model: 6ED1052-1FB00-0BA6) simplifies complex wiring by replacing multiple timers, relays, and counters. It is designed for 115/230V AC/DC environments and features an onboard display for real-time status monitoring and direct parameter adjustment. This module is an industry standard for building automation, HVAC control, and simple machine logic, providing a high degree of flexibility through its expandable I/O architecture.

Detailed Technical Specifications

The 6ED1052-1FB00-0BA6 (230RC) is built for localized control with high electrical resilience.

• Manufacturer: Siemens

• Model Series: LOGO! 6

• Model Designation: 230RC

• Order Number: 6ED1052-1FB00-0BA6

• Supply Voltage: 115 V AC/DC to 230 V AC/DC

• Permissible Range: 100 V to 253 V AC; 100 V to 253 V DC

• Digital Inputs: 8 AC/DC inputs (115/230V)

• Digital Outputs: 4 Relay outputs

• Output Switching Capacity: 5 A (inductive); 10 A (resistive)

• Short-Circuit Protection: External fusing required

• Clock: Integrated real-time clock with 80-hour power reserve

• Memory Capacity: 200 function blocks

• Display: Integrated LCD with background lighting

• Operating Temperature: 0 °C to +55 °C

• Storage Temperature: -40 °C to +70 °C

• Protection Class: IP20

• Mounting: 35mm DIN Rail (4 horizontal units wide)

• Dimensions: 72 mm x 90 mm x 55 mm

• Weight: 0.26 kg (0.57 lbs)
