900G01-0001 Honeywell | ControlEdge HC900 Digital Output Module
Manufacturer: Honeywell
-
Part Number: 900G01-0001
Condition：New with Original Package
Product Type: ControlEdge HC900 Digital Output Module
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Honeywell 900G01-0001 is a high-performance 16-point Digital Output Module for the ControlEdge HC900 system. It provides precise control of field devices such as relays, solenoids, and actuators. Designed for industrial applications, this module features a compact form factor, fast response times, and high-density outputs, ensuring reliability in demanding environments. Its robust construction and full electrical isolation make it ideal for critical automation processes.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | 900G01-0001 |
| Type | Digital Output Module |
| System Compatibility | Honeywell ControlEdge HC900 |
| Output Channels | 16 points |
| Output Voltage Range | 10–36 VDC |
| Nominal Output Voltage | 24 VDC |
| Output Current | 0.5 A per point, 8 A total |
| ON-State Voltage Drop | 0.3 VDC maximum |
| Isolation | 1500 VDC (channel to logic) |
| Response Time | 10 ms typical |
| Power Consumption | 2.0 W max from rack supply |
| Dimensions | Width: 1.2 in (30 mm), Height: 4.7 in (120 mm), Depth: 4.3 in (110 mm) |
| Weight | 0.4 lbs (0.18 kg) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | −40°C to 85°C (−40°F to 185°F) |
| Humidity Range | 5% to 95% RH, non-condensing |
| Mounting | HC900 I/O rack |
FAQ
Q1: What is the main purpose of the 900G01-0001?
A1: The 900G01-0001 controls digital field devices such as relays, actuators, and solenoids.
Q2: How many output channels does the 900G01-0001 provide?
A2: It provides 16 individual digital output channels.
Q3: What is the nominal voltage and current per channel?
A3: Each channel operates at 24 VDC with a maximum of 0.5 A.
Q4: What is the response time for the module?
A4: The typical response time is 10 milliseconds, suitable for fast industrial control.
Q5: What mounting options are available for this module?
A5: The 900G01-0001 mounts directly into the HC900 I/O rack.
