9662-610 | Triconex Digital Output Module with TMR Architecture

Product Description

Overview

The Triconex 9662‑610 (Part No. 7760050028) is a digital output module designed to drive solenoids, relays, lamps, and other field devices.
It provides high-integrity signal switching for safety-critical industrial applications.
Moreover, its Triple Modular Redundancy (TMR) architecture ensures fault-tolerant operation, continuous performance, and SIL 3 safety compliance.
The 610 revision and 7760050028 part number deliver enhanced hardware and firmware for reliable integration with modern Triconex controllers and chassis.

Technical Specifications

• Product Type: Digital Output Module / Terminal Board

• Model Number: 9662‑610

• Part Number: 7760050028

• Manufacturer: Schneider Electric (Triconex brand)

• System Compatibility: Triconex SIS (Tricon/Trident platforms)

• Architecture: Triple Modular Redundancy (TMR)

• Number of Channels: 32 isolated digital output channels

• Output Signal Types: 24 VDC logic outputs, relay drive

• Output Voltage Range: 18–32 VDC typical

• Output Current Capacity: Up to 0.5 A per channel (depending on load type)

• Isolation: Channel-to-channel and channel-to-system

• Diagnostics: Built-in self-diagnostics, fault detection, redundancy monitoring

• Safety Integrity Level: SIL 3 compliant

• Certifications: UL, CE, ATEX, IECEx

• Operating Temperature: –20 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5–95% RH (non-condensing)

• Dimensions (H × W × D): 187 × 114 × 25 mm

• Weight: 1.6 kg

FAQ

Q1: How many digital output channels does the module support?
It provides 32 isolated channels for driving discrete field devices reliably.

Q2: What type of output signals are supported?
The module supports 24 VDC logic outputs and relay drive.

Q3: Is the 9662‑610 SIL certified?
Yes, it is SIL 3 compliant, meeting IEC 61508 standards.

Q4: What improvements come with part number 7760050028?
This revision offers enhanced compatibility with newer Triconex chassis and advanced diagnostic features.

Q5: Can it operate in harsh industrial environments?
Yes, it functions reliably from –20 °C to +60 °C and includes robust channel-to-system isolation.
