9771-210F TRICONEX | Special Connector Digital I/O Termination
Manufacturer: Triconex
-
Part Number: 9771-210F
Condition：New with Original Package
Product Type: Special Connector Digital I/O Termination
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
TRICONEX 9771-210F Termination and I/O Interface Module is a high-integrity solution designed for Schneider Electric’s Triconex TMR (Triple Modular Redundant) safety and control systems. This “F” variant offers special connector types and enhanced LED diagnostics, providing flexible wiring and reliable monitoring. Moreover, it ensures accurate digital input/output signal transmission with optical and electrical isolation, making it suitable for demanding industrial environments.
The 9771-210F supports up to 64 I/O channels and integrates seamlessly with Triconex controllers, maintaining operational reliability even if a single module fails. In addition, its rugged design and compliance with API 670 and IEC safety standards make it ideal for applications in emergency shutdown (ESD), fire & gas systems, turbine and compressor control, and other critical process automation tasks. LED indicators simplify maintenance, allowing quick fault detection and system monitoring.
Technical Specifications:
| Specification | Details |
|---|---|
| Product Type | Termination / I/O Interface Module |
| Model Number | TRICONEX 9771-210F |
| Manufacturer | Schneider Electric (Triconex) |
| Function | Field wiring termination for digital I/O signals |
| I/O Channels | Up to 32–64 channels depending on configuration |
| Signal Types | Digital input/output, nominal 24 VDC |
| Isolation | Optical/electrical isolation between channels |
| Response Time | ≤1 ms typical |
| LED Indicators | Per-channel status LEDs for diagnostics (enhanced for “F” variant) |
| Power Supply | 24 VDC nominal (from Triconex backplane) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5%–95%, non-condensing |
| Mounting | Rack-mount or panel-mount options |
| Dimensions | 114 × 127 × 108 mm |
| Weight | 0.8–1.0 kg |
| Protection Class | IP20 (cabinet installation) |
| Compliance | API 670, IEC, Triconex safety standards |
| Diagnostics | Real-time fault detection and LED indication |
| Architecture | Triple Modular Redundant (TMR) |
| Input Voltage Range | 100–240 V AC/DC |
| Output Voltage | 24 V DC |
| Output Current | Maximum 5 A |
| Operating Temperature Range | –25 °C to +60 °C |
FAQ:
Q1: How many I/O channels does the 9771-210F support?
A1: It supports up to 32–64 digital input/output channels depending on configuration.
Q2: What is the advantage of the “F” variant?
A2: The “F” variant offers special connectors and enhanced LED diagnostics for flexible installation.
Q3: Can this module operate in harsh industrial environments?
A3: Yes, its rugged design and IP20 protection ensure reliable operation under demanding conditions.
Q4: What input and output voltages does it support?
A4: Input voltage ranges from 100–240 V AC/DC, and output voltage is 24 V DC.
Q5: How do LED indicators help in maintenance?
A5: LED diagnostics provide real-time channel status, simplifying troubleshooting and system monitoring.
