A6500-UM – EPRO Multi-Sensor Universal Measurement Module
Manufacturer: Epro
-
Part Number: 6500-UM
Condition：New with Original Package
Product Type: Sensor Universal Measurement Module
-
Country of Origin: Germany
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
EPRO A6500-UM – Universal Measurement Card
Product Overview
The EPRO A6500-UM is a high-performance Universal Measurement Card designed for the AMS 6500 ATG machinery protection system. It supports multiple sensor types, including eddy-current displacement sensors, piezoelectric accelerometers, seismic sensors, LVDTs, and Hall-effect devices. This card enables precise monitoring of shaft vibration, bearing vibration, axial displacement, speed, and position in rotating machinery.
Fully API 670-compliant, the A6500-UM card is hot-swappable, allowing maintenance or upgrades without system shutdown. Its compact 3U single-slot design reduces cabinet space requirements while providing advanced signal processing for critical industrial applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | A6500-UM |
| Channels | 2 (independent or combined) |
| Sensor Types Supported | Eddy-current, piezoelectric, seismic, LVDT, Hall-effect |
| Analog Outputs | 0/4–20 mA isolated, 0–10 V proportional |
| Digital I/O | 5 inputs, 6 outputs |
| Buffered Outputs | Front and rear |
| Communication | RS-485, Modbus RTU/TCP/IP, USB |
| Power Supply | 24 VDC |
| Operating Temperature | –40 °C to +85 °C |
| Accuracy | ±0.1% of full scale |
| Sampling Rate | Up to 10 kHz |
| Compliance | API 670, IEC, ATEX (with barriers) |
| Mounting | 3U rack-mounted in A6500-SR system rack |
FAQ
1. What sensors can I connect to the A6500-UM card?
It supports eddy-current, piezoelectric, seismic, LVDT, and Hall-effect sensors for multi-parameter monitoring.
2. Is the card hot-swappable?
Yes, it can be replaced without shutting down the AMS 6500 system, minimizing downtime.
3. What outputs are available for monitoring?
It provides isolated 0/4–20 mA, 0–10 V proportional outputs, and buffered front/rear outputs.
4. Which communication protocols are supported?
RS-485, Modbus RTU, Modbus TCP/IP via A6500-CC, and USB for configuration.
5. Can it operate in harsh industrial environments?
Yes, it functions from –40 °C to +85 °C and is compliant with ATEX when installed with certified barriers.
