ABB DATX100 | Pulse Transformer Board for Automation
Manufacturer: ABB
-
Part Number: 3ASC25H208 DATX100
Condition：New with Original Package
Product Type: Pulse Transformer Board for Automation
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The ABB DATX100 (3ASC25H208) is a precision pulse transformer board designed for ABB control and automation systems. It converts analog signals—such as 0–10 V or 4–20 mA—into clean, stable pulse outputs for precise equipment monitoring. This module is widely used in power generation, industrial machinery, and substation automation where signal accuracy and reliability are critical.
Built to ABB’s high engineering standards, the DATX100 ensures exceptional performance even under electrical noise and harsh industrial conditions. Moreover, it supports redundant operation and user-defined logic programming, allowing flexible integration into both new and existing ABB control architectures.
Technical Specifications
| Attribute | Specification |
|---|---|
| Model | DATX100 |
| Part Number | 3ASC25H208 |
| Type | Pulse Transformer Board |
| Analog Input Channels | 2 channels; supports 0–10 V, 0–20 mA, 1–5 V |
| Input Voltage | 24 VDC (operational range: 20.4–26.4 VDC) |
| Output Voltage (ON) | ≤ 2 VDC |
| Leakage Current (OFF) | ≤ 0.1 mA |
| Max Load Current | 100 mA per channel (at 26.4 VDC) |
| Communication Protocols | Modbus, EtherNet/IP |
| Programmability | User-defined logic configuration supported |
| Redundancy | Yes, supports redundant configuration |
| Net Weight | 1.03 kg |
| UNSPSC Code | 39120000 |
| Environmental Compliance | Not in WEEE scope |
| Country of Origin | United States / Sweden |
FAQ
Q1: What is the main function of the ABB DATX100?
A1: The DATX100 converts analog signals into precise pulse outputs for monitoring and control in ABB automation systems.
Q2: Which communication interfaces does it support?
A2: It supports Modbus and EtherNet/IP for reliable and fast data communication.
Q3: Does the module support redundancy?
A3: Yes, it includes redundancy support for continuous and fault-tolerant operation.
Q4: What type of input signals can the DATX100 handle?
A4: It handles 0–10 V, 0–20 mA, and 1–5 V analog input signals.
Q5: Where is the ABB DATX100 manufactured?
A5: It is manufactured in the United States or Sweden under ABB’s strict quality standards.
