ABB S4C+ IRC5 Analog Board DSQC355 3HNA018564-001 New

Product Description

Precision Analog Interface and Motion Control Computing

The DSQC355 (Part Number: 3HNA018564-001) is a specialized high-performance module designed for ABB S4C+ and IRC5 robot controllers. This unit functions as both an analog I/O interface and an axis computer board, playing a pivotal role in the robot's motion control system. The DSQC355 (3HNA018564-001) is responsible for executing complex servo calculations and processing feedback signals from encoders and resolvers. By translating digital commands into precise analog control signals for servo amplifiers, it ensures the smooth, synchronized, and highly accurate positioning required for sophisticated robotic tasks.

Detailed Technical Specifications

The DSQC355 3HNA018564-001 (also associated with 3HNE00554-1) is built to industrial standards to ensure low-latency signal processing and high thermal stability.

• Manufacturer: ABB

• Model Designation: DSQC355 (Catalog version DSQC 355B)

• Product ID: 3HNA018564-001 / 3HNE00554-1

• Primary Function: Axis Computer and Analog I/O Processing

• System Compatibility: ABB S4C+ and IRC5 Robot Controllers

• Input Voltage: 24 V DC (Supplied via the controller backplane)

• Signal Support: High-resolution Resolver and Encoder feedback

• I/O Capability: Integrated Analog Input/Output channels for auxiliary process control

• Communication Interface: Proprietary ABB high-speed bus system

• Diagnostic Features: On-board LED indicators for axis status, power, and communication faults

• Operating Temperature: 0 °C to +45 °C

• Storage Temperature: -25 °C to +70 °C

• Product Net Dimensions: 200 mm (L) x 190 mm (W) x 55 mm (H)

• Net Weight: 1.2 kg (Gross weight 1.2 kg)

• Country of Origin: Sweden / USA (Global sourcing dependent)
