ABB UFC760BE143 System 800xA Controller CPU Module
Manufacturer: ABB
-
Part Number: UFC760BE143 3BHE004573R0143
Condition：New with Original Package
Product Type: Controller ModuleS
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
ABB UFC760BE143 Controller Module
Configured for high-speed process control in System 800xA networks, the ABB UFC760BE143 (3BHE004573R0143 Controller Module) provides direct electrical execution of complex control logic and I/O signal coordination.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | UFC760BE143 (3BHE004573R0143) |
| Brand | ABB |
| Origin | Switzerland |
| Weight | 0.46 kg |
| Dimensions | 155 x 125 x 85 mm |
| Operating Temp | -20 deg C to +60 deg C |
| Power Consumption | 12 W to 15 W @ 24 VDC |
| MTBF | >500,000 hours |
ABB Industrial Control Characteristics
The UFC760BE143 module facilitates deterministic communication across the backplane bus, ensuring high-speed data transfer between the CPU and remote I/O nodes. The internal RISC architecture manages I/O density scaling efficiently, allowing the module to maintain scan cycle precision even when interfaced with diverse subsystem loads. Technicians can deploy firmware flash compatibility to update controller logic protocols, ensuring the module remains aligned with current System 800xA software revisions. Furthermore, the unit integrates Profinet and EtherNet/IP connectivity to sustain deterministic network performance across plant-wide distributed control architectures.
Frequently Asked Questions
Q: Does the UFC760BE143 support hot-swapping during active system runtime?
A: The module supports hot-swapping within a redundant controller pair configuration, provided the primary/secondary switchover logic is active and the chassis backplane power remains stable.
Q: How does the module maintain synchronization in a redundant configuration?
A: The dual CPU configuration continuously monitors the status of the standby module via a dedicated high-speed link, ensuring that internal state variables synchronize in real-time to minimize failover latency.
Field Installation Guidelines
- ESD Handling: Always utilize a grounded anti-static wrist strap before handling the circuit board to prevent electrostatic discharge damage to the processor's sensitive CMOS components.
- Backplane Insertion: Align the module carefully with the cabinet guide rails. Apply consistent pressure to the front faceplate until the rear-edge connector securely engages with the backplane bus, then engage the locking mechanism.
- Shielding: Terminate cable shields at the designated cabinet grounding rail to suppress EMI/RFI noise. Keep data communication paths physically separated from high-voltage AC output circuits.
- Validation: Initiate the power-up sequence and verify the status LEDs on the front panel. A successful boot confirms that the processor passed all internal hardware self-tests and established communication with the main control network.
