AD202MU | Foxboro Field Termination Assembly for FBMs

Product Description

Product Overview

The Foxboro FBM-FTA AD202MU provides a reliable field wiring interface for Foxboro I/A Series control systems.
It connects field instruments to Field Bus Modules while maintaining signal integrity in demanding industrial environments.
Moreover, this Field Termination Assembly simplifies installation by separating field wiring from sensitive control electronics.
Its robust construction supports continuous operation across oil, gas, power, and chemical processing facilities.
Therefore, engineers rely on the AD202MU for long-term, stable signal termination solutions.

Technical Specifications

Product Type: Field Termination Assembly (FTA)
Model Number: FBM-FTA AD202MU
Manufacturer: Foxboro (Schneider Electric / Invensys)
Country of Origin: USA

System Compatibility:

• Foxboro I/A Series Distributed Control System

• Compatible with Foxboro Field Bus Modules (FBMs)

Electrical and Signal Characteristics:

• Supported Signal Types: Analog (mA, V), Digital (24 VDC), temperature signals depending on FBM

• Isolation: Channel-to-channel and channel-to-system isolation when paired with FBM

• Surge Protection: Optional transient suppression modules

Mechanical and Installation:

• Terminal Count: Typically 32–64 terminals depending on configuration

• Wiring Interface: Screw-type or spring clamp terminals

• Mounting: Panel or DIN rail mounting

Environmental Conditions:

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity Range: 5–95% RH, non-condensing

Physical Data:

• Weight: 0.65 kg

• Shipping Options: FedEx or DHL available

Commercial Information:

• Inventory Status: In stock, limited quantity

• Certification: C/O from Chamber of Commerce, C/Q from Manufacturer

FAQ

Q1: What is the primary function of the Foxboro AD202MU?
Moreover, it provides a secure field wiring interface between field devices and Foxboro FBMs.

Q2: Is the AD202MU compatible with all Foxboro FBMs?
It supports multiple FBM types, including analog, digital, and temperature input modules.

Q3: Does this FTA provide signal isolation?
In addition, isolation depends on the paired FBM and optional surge protection configuration.

Q4: Can field wiring be serviced without removing FBMs?
Yes, the design allows wiring maintenance without disturbing installed FBM electronics.

Q5: Is the AD202MU suitable for harsh industrial environments?
Therefore, its industrial design supports reliable operation under vibration, temperature, and electrical noise.
