AD206HQ | FOXBORO Analog Input for Foxboro I/A Series
Manufacturer: Foxboro
-
Part Number: AD206HQ
Condition：New with Original Package
Product Type: Analog Input for Foxboro I/A Series
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
FOXBORO AD206HQ | Analog Input Module
Product Overview
The FOXBORO AD206HQ is a high-precision analog input module designed for use in Foxboro Distributed Control Systems (DCS). It delivers six isolated, high-resolution analog inputs for accurate monitoring of critical process variables, including temperature, pressure, flow, and level.
Built for demanding industrial environments, the AD206HQ features 16-bit resolution, robust electrical isolation, and fast signal acquisition. Its compact and modular design ensures easy integration into control cabinets or baseplates, making it ideal for chemical processing, power generation, pharmaceutical, and water treatment applications.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | AD206HQ |
| Type | Analog Input Module |
| Input Channels | 6 isolated analog inputs |
| Signal Type | Voltage or current (0–10 V DC, 4–20 mA) |
| Resolution | 16-bit ADC |
| Input Voltage | 24 V DC |
| Output Voltage | 0–10 V DC (for signal conditioning or loopback) |
| Communication Interface | RS-485 |
| Isolation | Channel-to-channel and channel-to-ground |
| Operating Temperature | –10°C to +60°C |
| Dimensions | 100 mm × 80 mm × 20 mm |
| Mounting Type | DIN rail or panel mount |
| Certifications | CE, RoHS, IEC 61131-2 compliant |
FAQ
Q: How many analog inputs does the AD206HQ support?
A: The AD206HQ provides six isolated analog input channels.
Q: What signal types are compatible?
A: It supports voltage (0–10 V DC) and current (4–20 mA) signals.
Q: Can the module operate in harsh industrial environments?
A: Yes, it is designed for reliability in chemical, pharmaceutical, power, and water treatment facilities.
Q: Is the AD206HQ easy to install?
A: Yes, it supports DIN rail or panel mount installation for fast deployment.
Q: What communication interface does it use?
A: The module communicates via RS-485 interface for reliable system integration.
