ALE111-S00 | Yokogawa | Ethernet Communication Module

Description

• Manufacturer: Yokogawa
• Part Number: ALE111-S00
• Product Name: ALE111 Ethernet Communication Module

Specifications

• Type: Standard Type
• Basic Type: 0
• Physical Layer Interface: IEEE802.3 10BASE-T
• Connection Method: Point-to-point
• Connector: RJ-45
• Transmission Method: Half-duplex
• Transmission Speed: 10 Mbps
• Transmission Route: 100 ohm twisted-pair cable (not shielded)
• Transmission Distance: 1 segment, 100 m (between FCS and subsystems, or HUB and subsystems)
• Installation Method: Mounted on ANB10?, ANB11?, ANR10?, AFF50?, AFV10?, AFV30?, or AFV40?
• Number of Ports: One port
• Media Access Control: CSMA/CD
• Communication Functions: Communications with FA-M3, Modbus, MELSEC, YFGW, DARWIN/DAQSTATION, and PLC-5/SLC500
• Current Consumption: 0.5 A
• Weight: 0.3 kg
• Shipping Weight: 1.5 kg
