Allen-Bradley Bulletin 1606 XL 1606-XL480E 24V 20A PSU

Product Description

Product Overview

1606-XL240DR is an Allen-Bradley (Rockwell Automation) Bulletin 1606 XL industrial DIN-rail power supply engineered for continuous, reliable DC power in demanding automation and process control environments.

This model provides 24 V DC output at 10 A (240 W) with a wide input range (AC 85…264 V or DC 90…150 V). Designed for N+1 redundancy, it includes a “RDY” relay contact for monitoring system status. Compact dimensions, DIN-rail mounting, and pluggable connectors allow fast installation in tight control cabinets. Global certifications ensure suitability for hazardous locations, marine applications, and SEMI F47 compliance.

Technical Specifications

Model / Catalog Number: 1606-XL240DR
Series: Bulletin 1606 XL

• Power Rating: 240 W

• Output Voltage: 24 V DC

• Output Current: 10 A

• Input Voltage (AC): 85–132 V AC / 176–264 V AC, 47–63 Hz

• Input Voltage (DC): 90–150 V DC

• Output Adjustment Range: 24–28 V DC

• Efficiency: 89%

• Ripple & Noise: <30 mVpp (typical), <100 mVpp max

• Overload Behavior: High overload current without shutdown (continuous current, no hiccup mode)

• Redundancy: N+1 redundancy capability

• Relay Contact: “RDY” contact for monitoring output status

• Operating Temperature: –25 °C to +70 °C (derating above +60 °C)

• Hold-Up Time: >25 ms at AC 196 V

• Mounting: DIN-rail, quick installation

• Dimensions (L×W×H): 124 × 124 × 60 mm

• Enclosure Rating: IP20

• Certifications: UL, cULus, CE, ATEX, SEMI F47, NEC Class 2, Class I Div. 2, Marine (ABS/GL/RINA), RoHS

• Weight: 0.98 kg

• Shipping Weight: 2 kg
