Bently Nevada 330180-90-CN 3300 XL Proximitor Sensor
Manufacturer: Bently Nevada
-
Part Number: 330180-90-CN
Condition：New with Original Package
Product Type: 3300 XL Proximitor Sensor
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Bently Nevada 330180-90-CN – 3300 XL Proximitor Sensor
Overview
The Bently Nevada 330180-90-CN is a 3300 XL 8 mm Proximitor Sensor, engineered for vibration and position monitoring in critical rotating machinery. It serves as a replacement for 330100-90-02 and 330100-90-05, providing improved performance and compliance. With robust construction and reliable accuracy, it is widely applied in turbines, compressors, and fluid-film bearing machines.
This model accepts 3300-series 5 mm, 3300 8 mm, and 3300 XL 8 mm probes with extension cables, ensuring full compatibility across multiple system configurations. Designed for panel mounting, it guarantees secure installation in demanding industrial conditions.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | 330180-90-CN |
| Product Type | 3300 XL Proximitor Sensor |
| System Length | 9.0 metres (29.5 ft) |
| Mounting Option | Panel mount |
| Replacement For | 330100-90-02, 330100-90-05 |
| Sensor Input | Accepts 3300-series 5 mm, 3300 8 mm, 3300 XL 8 mm probes |
| Material | A308 aluminum housing |
| Operating Temperature | –51 °C to +100 °C (–60 °F to +212 °F) |
| Storage Temperature | –51 °C to +105 °C (–60 °F to +221 °F) |
| Linear Range | 0.25 mm to 2.3 mm (10–90 mils) |
| Accuracy | ±0.25 mm over range (0 °C to +45 °C) |
| Power Supply | –17.5 Vdc to –26 Vdc |
| Compliance | Meets API 670 (4th Edition) standards |
| Target Calibration | AISI 4140 steel |
| Dimensions | Standard 3300 XL Proximitor form factor |
| Weight | 0.246 kg |
