Bently Nevada 990-05-XX-03-05 | Two-Wire Seismic Transducer
Manufacturer: Bently Nevada
-
Part Number: 990-05-XX-03-05
Condition：New with Original Package
Product Type: Two-Wire Seismic Transducer
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Bently Nevada 990-05-XX-03-05 is a two-wire seismic velocity transducer designed for measuring absolute vibration in machine casings, bearing housings, and structural components.
This 990 Series vibration transmitter uses a moving-coil mechanism to produce a voltage output directly proportional to vibration velocity. It is widely applied in industrial machinery protection and condition monitoring systems.
Although discontinued by the manufacturer, it remains highly reliable, and Radwell provides a 2-year warranty on this unit.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 990-05-XX-03-05 |
| Series | 990 Series |
| Sensor Type | Moving-coil velocity transducer (seismoprobe) |
| Sensitivity | 500 mV/in/s (20 mV/mm/s) ±5% at 100 Hz |
| Frequency Response | 10 Hz to 1 kHz |
| Connector Type | Coaxial connector (Option 05) |
| Mounting Base | Isolated rectangular flange (Option 03) |
| Cable Length | Customizable (XX = user-defined) |
| Power Supply | Self-powered (no external power required) |
| Operating Temperature | –29°C to +121°C (–20°F to +250°F) |
| Maximum Cable Distance | Up to 305 m (1,000 ft) to monitoring system |
| Environmental Rating | Industrial-grade; corrosion-resistant housing |
| Applications | Vibration monitoring in turbines, compressors, motors, and pumps |
FAQ
Q1: Is this sensor new or used?
A1: The 990-05-XX-03-05 is discontinued by the manufacturer, but Radwell provides a 2-year warranty.
Q2: What is the sensitivity of this vibration transmitter?
A2: It has a sensitivity of 500 mV/in/s (20 mV/mm/s) ±5% at 100 Hz.
Q3: What frequency range does it cover?
A3: The sensor operates typically from 10 Hz to 1 kHz.
Q4: What type of mounting base does it use?
A4: It uses an isolated rectangular flange (Option 03).
Q5: Can I use it for long cable runs?
A5: Yes, it supports up to 305 m (1,000 ft) between the sensor and monitoring system.
Q6: Is external power required?
A6: No, it is self-powered.
