Bently Nevada 991-25-50-01-00 | OEM Machinery Thrust Monitoring Device
Manufacturer: Bently Nevada
-
Part Number: 991-25-50-01-00
Condition：New with Original Package
Product Type: OEM Machinery Thrust Monitoring Device
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Bently Nevada 991-25-50-01-00 is a compact thrust transmitter designed for OEM applications, including centrifugal compressors, small pumps, motors, and fans. It provides an accurate 4–20 mA linear signal proportional to axial displacement (thrust).
Its compact DIN-rail mounting design allows easy integration into machinery and control systems where full vibration monitoring is not required. The transmitter supports loop-powered operation (12–36 VDC) and operates reliably across a wide temperature range, enabling continuous machinery protection.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | 991-25-50-01-00 |
| Product Type | Thrust Vibration Transmitter |
| Measurement Type | Axial displacement (thrust) |
| Output Signal | 4–20 mA linear |
| Measurement Range | 0 to 50 mils (0 to 1.27 mm) |
| Power Supply | Loop-powered, 12–36 VDC |
| Sensor Type | Eddy-current proximity probe |
| Operating Temperature | –40°C to +85°C |
| Mounting Configuration | 35 mm DIN rail clips, compact OEM design |
| Weight | 1.05 lbs |
| Applications | Centrifugal compressors, small motors and pumps, OEM thrust monitoring, control system integration |
FAQs
Q1: Is the Bently Nevada 991-25-50-01-00 brand new?
A1: Yes, all 991-25-50-01-00 transmitters are brand new and original, supplied with a Radwell 2-year warranty.
Q2: What is the measurement range for this transmitter?
A2: It measures axial displacement from 0 to 50 mils (0 to 1.27 mm).
Q3: How is this transmitter powered?
A3: The 991-25-50-01-00 is loop-powered, requiring 12–36 VDC for operation.
Q4: What type of output signal does this transmitter provide?
A4: It outputs a 4–20 mA linear signal proportional to thrust.
Q5: Where can this transmitter be used?
A5: Ideal for centrifugal compressors, pumps, motors, and other OEM machinery requiring thrust monitoring.
