BMXXBC008K Backplane Module | Schneider Electric X80 System
Manufacturer: Schneider
-
Part Number: BMXXBC008K
Condition：New with Original Package
Product Type: Backplane Bus Base Module
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Schneider Electric BMXXBC008K is a high-performance backplane bus base module for the Modicon X80 automation platform, compatible with M340 and M580 systems. This module provides the backbone for mounting and interconnecting up to 8 CPU, I/O, or communication modules in a single rack, ensuring reliable power distribution, high-speed data exchange, and robust mechanical support.
With its industrial-grade design, BMXXBC008K is ideal for medium automation projects, delivering scalable architecture and seamless integration with Modicon platforms. It supports DIN rail or panel mounting for flexible installation.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model Number | BMXXBC008K |
| Product Type | Backplane Bus Base Module |
| Platform | Modicon X80 (compatible with M340 & M580) |
| Number of Slots | 8 module positions |
| Supported Modules | CPUs, power supplies, communication modules, discrete/analog I/O |
| Bus Type | X‑Bus (high-speed backplane bus) |
| Power Distribution | Provides 5 V DC and internal bus power via rack power supply |
| Communication | Ensures synchronization and data exchange between modules |
| Connectors | 2 × SUB-D 9 Male connectors (backplane cable) |
| Cable Length | 0.8 m |
| RoHS Compliant | Yes |
| Operating Temperature | 0–60 °C |
| Storage Temperature | –40–85 °C |
| Operating Humidity | Max 80% RH, non-condensing |
| Storage Humidity | Max 80% RH, non-condensing |
| Operating Environment | Clean indoor, no corrosive chemicals |
| Maximum Altitude | 1000 m |
| Storage Altitude | 1000 m |
| Dimensions (W × H × D) | 450 × 145 × 90 mm |
| Weight | 0.38 lbs (0.17 kg) cable; 1.2–1.5 kg module |
| Certifications | CE, UL, CSA, IEC compliance |
| Lifecycle | Active; supported in M340/M580 platforms |
