BMXXSP1200 Schneider | Shielding Kit for Modicon X80 12-Slot Racks

Product Overview

The Schneider Electric BMXXSP1200 is a shielding connection kit designed for Modicon X80 12-slot backplanes. It provides a controlled grounding path for cable shields, helping maintain signal stability in industrial automation systems.

This accessory supports Modicon M340 and M580 PAC architectures. Moreover, it plays a critical role when analog I/O modules operate in electrically noisy environments.

By ensuring proper shield termination, the BMXXSP1200 reduces electromagnetic interference and electrostatic discharge risks. Therefore, it improves measurement accuracy and long-term system reliability.

Technical Specifications

Product Type
Shielding connection kit

Model
BMXXSP1200

Series
Modicon X80 accessories

Compatible Backplane
Modicon X80, 12-slot

Included Components
2 bases
1 metal grounding bar

Primary Function
Shield connection for cable shields
Electrostatic discharge prevention

Net Weight
0.4 kg

Packaging Quantity
1 unit per package

Packaging Dimensions
52.0 cm × 9.0 cm × 4.5 cm

Packaging Weight
416 g

Bulk Packaging
20 units per box
Box size: 60 × 40 × 30 cm
Gross weight: 9.266 kg

Environmental Compliance
REACh compliant
China RoHS compliant
Not within EU RoHS scope

FAQ

What is the main purpose of the BMXXSP1200?
It provides proper grounding for cable shields, reducing noise and electrostatic discharge in analog I/O systems.

Which Schneider platforms support this shielding kit?
It supports Modicon X80 systems used with Modicon M340 and M580 controllers.

Is this kit required for all X80 installations?
It is recommended when analog signals operate near electrical noise sources or sensitive measurement circuits.

What components are included in the package?
Each package includes two mounting bases and one metal grounding bar.

Does Schneider provide warranty coverage?
Yes, Schneider Electric provides an 18-month standard warranty for this accessory.
