BNC Terminator 30731832-001 | Honeywell Industrial Control Component
Manufacturer: Honeywell
-
Part Number: 30731832-001
Condition：New with Original Package
Product Type: Industrial Control Component
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The HONEYWELL 30731832-001 is a high-precision BNC Terminator Plug designed for Honeywell’s Universal Control Network (UCN) and TDC 3000 distributed control systems. It terminates unused coaxial communication ports, ensuring proper impedance matching and preventing signal reflections. Its nickel-plated brass construction and internal precision resistor guarantee long-term reliability. The compact design allows easy installation in tight spaces, and the plug resists vibration, dust, and EMI.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | 30731832-001 |
| Type | BNC Terminator Plug |
| Impedance | 75 ohms |
| Connector Type | Male BNC |
| Functionality | Terminates open coaxial cable ends; prevents signal reflection and distortion |
| Material | Nickel-plated brass housing with internal precision resistor |
| Dimensions | Compact form factor, easily integrates in control racks |
| Weight | Approx. 20 grams (0.04 lbs) |
| Operating Temperature | −20°C to +70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Environmental Resistance | Resistant to vibration, dust, and EMI |
| Compliance | CE marked; meets Honeywell industrial safety and EMC standards |
| Shipping Weight | 0.90 kg |
| Item Weight | 0.40 kg |
FAQ
Q1: What is the primary function of the 30731832-001?
A1: It terminates unused coaxial ports in UCN/TDC 3000 systems, preventing signal reflections.
Q2: What is the impedance of this BNC terminator?
A2: The 30731832-001 has a 75-ohm impedance for proper network termination.
Q3: Can it withstand harsh industrial conditions?
A3: Yes, it resists vibration, dust, EMI, and operates from −20°C to +70°C.
Q4: What materials are used in the construction?
A4: It features a nickel-plated brass housing with an internal precision resistor.
Q5: Is it compatible with Honeywell UCN and TDC 3000 systems?
A5: Yes, it is specifically designed for these distributed control networks.
