Product Description

The Honeywell CC-TDIL51 Digital Input IOTA provides reliable signal termination for discrete field devices in Experion PKS and C300 systems. It supports stable acquisition of digital inputs while maintaining high immunity to electrical noise in demanding industrial environments. Moreover, its compact form factor allows engineers to integrate it easily into Series C architectures without redesigning existing wiring.

This model is widely used in mission-critical plants where continuous monitoring of switches, relays, and sensors is essential. Therefore, process engineers value its dependable performance and strong isolation, which help maintain consistent system behavior during plant operations.

Technical Specifications

Attribute — Specification

• Model Number: CC-TDIL51

• Part Number: 51307083-175

• Type: Digital Input Module

• System Compatibility: Experion PKS / Series C I/O

• Channels: 32 digital input channels

• Input Voltage: 24 VDC nominal

• Signal Type: Discrete ON/OFF inputs from switches, relays, sensors

• On-State Threshold: ≥12 VDC

• Off-State Threshold: ≤5 VDC

• Input Current: 7–10 mA typical per channel

• Isolation: Channel-to-channel and channel-to-system

• Noise Immunity: High, suitable for industrial noise environments

• Diagnostics: Fault detection and integrity monitoring

• Dimensions: 127 × 89 × 32 mm

• Weight: 0.45 kg

• Operating Temperature: –20 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Certifications: CE, UL, CSA, TUV

• Origin: USA

FAQ

1. What type of devices can connect to the CC-TDIL51?
It supports switches, relays, limit sensors, and other discrete 24 VDC devices.

2. Does the module offer input isolation?
Yes, it provides channel-to-channel and channel-to-system isolation for noise protection.

3. Is it compatible with all Experion PKS systems?
It integrates fully with Experion PKS and Honeywell Series C I/O environments.

4. How many inputs does the module support?
The device supports 32 independent digital input channels.

5. Does it provide diagnostic features?
Yes, the built-in diagnostics monitor signal integrity and detect wiring faults.
