CI520V1 ABB | Industrial Analog I/O Module for Advant Systems
Manufacturer: ABB
-
Part Number: CI520V1 3BSE012869R1
Condition：New with Original Package
Product Type: Industrial Analog I/O Module for Advant Systems
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
ABB CI520V1 Analog Input/Output Communication Module
Overview
The ABB CI520V1 is a high-performance analog input/output isolation module for Advant Controller 410 and 450 systems.
It integrates 4 analog inputs and 4 analog outputs in a single plug-in card, reducing cabinet wiring and saving space.
Equipped with 16-bit A/D and D/A conversion, the CI520V1 delivers high accuracy (±0.1% full scale) and fast response times ≤10 ms.
The module features robust electrical isolation (≥1500 VAC) between channels and the backplane, ensuring signal integrity and system reliability.
Hot-swappable design allows maintenance without system shutdown, and LED indicators show power, channel status, and faults for quick diagnostics.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | CI520V1 |
| Part Number | 3BSE012869R1 |
| Module Type | Analog Input/Output Isolation Module |
| Analog Inputs | 4 channels (0–20 mA, 4–20 mA, 0–10 V selectable) |
| Analog Outputs | 4 channels (0–20 mA, 4–20 mA, 0–10 V selectable) |
| Resolution | 16-bit A/D and D/A conversion |
| Accuracy | ±0.1% Full Scale |
| Isolation Voltage | ≥1500 VAC between channels and backplane |
| Response Time | ≤10 ms for both input and output |
| Input Impedance | ≥100 Ω (current), ≥100 kΩ (voltage) |
| Output Load Capacity | ≤600 Ω (current), ≥2 kΩ (voltage) |
| Power Supply | 5 V DC (from rack backplane) |
| Power Consumption | ≤3 W |
| Operating Temperature | –20 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5% to 95%, non-condensing |
| Mounting Type | Plug-in card, hot-swappable |
| LED Indicators | Power (green), Channel Status (yellow), Fault (red) |
| EMC Compliance | IEC 61326 Industrial Standard |
| Net Weight | 0.145 kg |
| Application Areas | Industrial automation, process control, DCS systems |
FAQs
Q1: Which systems are compatible with the CI520V1?
✅ It works with ABB Advant Controller 410 and 450 series systems.
Q2: How many analog input and output channels does it provide?
✅ The module supports 4 analog inputs and 4 analog outputs, with selectable ranges.
Q3: Can the module be replaced without shutting down the system?
✅ Yes, it is hot-swappable, allowing maintenance without system interruption.
Q4: What is the accuracy and resolution of the module?
✅ It features 16-bit A/D and D/A conversion with ±0.1% full-scale accuracy.
Q5: Does it offer electrical isolation?
✅ Yes, all channels have ≥1500 VAC isolation from the backplane.
