Digital I/O Termination Board GE DS200TBQBG1A for Mark V Series

GE DS200TBQBG1A Digital I/O Termination Module – Product Description

The GE DS200TBQBG1A module provides dependable termination points for digital signal wiring inside Mark V Speedtronic systems, ensuring stable connections for demanding turbine control environments. Moreover, its rugged construction and clean layout help technicians complete installation work quickly while maintaining consistent system integrity. The board supports multiple digital channels, and it integrates seamlessly with existing GE Mark V hardware without modification.

This module uses barrier-style terminal blocks that simplify field wiring and reduce the chances of signal noise during high-load operation. In addition, its isolation design enhances reliability by separating field signals from the backplane, protecting the control system during fluctuating electrical conditions. Engineers who require predictable performance in harsh sites often choose this module because it delivers consistent behavior across broad temperature ranges.

Technical Specifications

• Manufacturer: General Electric (GE)

• Part Number: DS200TBQBG1A

• Series: Mark V DS200 (Speedtronic Turbine Control System)

• Functional Acronym: TBQB

• Product Type: Digital I/O Termination Module

• Application: Terminal interface for digital inputs and relay-driven outputs

• Channel Capacity: Typically 24–32 digital I/O channels

• Signal Type: Dry contact inputs and relay-based outputs

• Connector Type: Barrier-style terminal blocks

• Isolation: Optical/electrical isolation between field signals and backplane

• PCB Coating: Normal protective coating

• Revision: G1A

• Dimensions: 33 cm × 17.8 cm

• Weight: 0.5 kg (≈1.1 lbs)

• Operating Temperature: –20 °C to +70 °C

• Storage Temperature: –40 °C to +85 °C

• Installation: Rack-mounted, hot-swappable within Mark V systems

FAQ

Q: Is the DS200TBQBG1A compatible with all GE Mark V systems?
Yes, the module is designed specifically for Mark V architectures and integrates without requiring additional adapters.

Q: Does this module support mixed input and output wiring?
Yes, it provides termination points for both digital input channels and relay-driven output paths.

Q: Can field technicians replace this board during live operation?
Yes, its hot-swappable design allows fast replacement when proper safety procedures are followed.

Q: How does the module address electrical noise in turbine environments?
It uses isolation and filtering methods that reduce interference and improve signal stability.

Q: Is any special coating available for corrosive industrial sites?
This version includes a normal coating, although other DS200 variants offer enhanced protection if required.
