DS200TCQAG1BHF | Analog I/O Board | GE Fanuc

Overview

The DS200TCQAG1BHF is an Analog I/O Board designed for the Mark V Series of turbine control systems by General Electric. It handles critical analog I/O functions for signal processing and system control.

Key Features

• Connectors: Four 34-pin connectors, two 40-pin connectors.
• LEDs: Equipped with six LEDs for diagnostics.
• Mounting: Designed with six mounting holes for secure installation.

Installation Tips

• Handling: Avoid dropping screws or washers into the board cabinet to prevent damage or electrical hazards.
• Assembly: Use washers and screws when installing or replacing the board; do not overtighten to avoid damage.

Safety Considerations

• High Voltage: Ensure no metal parts fall into the cabinet during installation to prevent electrical shock or fire hazards.
