DSAV111 ABB | Real-Time Video Board for Industrial Automation
Manufacturer: ABB
-
Part Number: DSAV111
Condition：New with Original Package
Product Type: Real-Time Video Board for Industrial Automation
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The ABB DSAV111 is a high-performance video driver module designed for ABB MasterView 800 and Advant OCS control systems. It functions as a video board enabling real-time visual data processing and smooth graphical display, with a frame rate of up to 61.2 Hz.
The DSAV111 features 16 digital inputs and 16 digital outputs, and supports communication via Ethernet and RS485, allowing operators to monitor and control industrial processes efficiently. Its rugged design ensures reliable performance in harsh environments such as power generation, chemical plants, and critical automation systems.
This module includes built-in diagnostics, status indicators, and supports ladder logic and structured text programming, simplifying maintenance and operational reliability. Note that it is an exchange part, and replaced units must be returned according to ABB RMA terms to avoid extra charges.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | DSAV111 |
| Product Type | Video Board Module |
| System Compatibility | ABB MasterView 800, Advant OCS |
| Frame Rate | Up to 61.2 Hz |
| Input Voltage | 24 V DC |
| Operating Temperature | –40°C to +70°C |
| Communication Interfaces | Ethernet, RS485 |
| Memory Capacity | 256 KB |
| Digital Inputs | 16 channels |
| Digital Outputs | 16 channels |
| Design Features | Compact, rugged, ladder logic & structured text support |
| Diagnostics | Built-in fault monitoring and status indicators |
| Net Weight | 0.395 kg |
| Application Areas | Industrial automation, remote monitoring, visual control systems |
